A network architect is designing a wireless solution for a company that is leasing one floor in a multi-floor building in a downtown area. The customer is concerned about ensuring complete Wi-Fi coverage and pin-pointing RF hazards. What type of survey should the network architect perform?

A network architect is designing a new Wi-Fi solution for a customer The customer currently occupies a one-story building on a small campus. In one part of the building there is an auditorium, where the ceiling height and attenuation is different from the rest of the building. What should the network architect create in VisualRF to identify this difference when planning :ne APs?

A network architect is replacing an old wireless implementation based on 802.11 a with a new wireless solution. The company has a lot of money invested in legacy wireless barcode scanners and will not be replacing them. However, the bandwidth that the company expects each AP to have less than 700 Mbps in bandwidth, and this is not expected to change in the future.

Which wireless solution would best meet this company's needs and be the most cost-effective?

A network architect wants to estimate the number of Aruba APs that will be needed Tor a new wireless design and determine the wireless coverage using VisualRF. The company requires a high-density design. The building has 200.000 square feet. How many APs should the network architect add to VisualRF in order to perform the coverage analysis?

What is the main key for a network design to ensure users have a good experience running their applications'?

A university department has a program in video processing and editing. Students in the department use Wi-Fi to interact with the video servers. The editing and processing is done by the students accessing and using the video servers. However, the students must then stream their results, via Wi-Fi to their laptops to verify the results. A network architect has determined that no more than 20 APs will be needed for the Wi-Fi solution. Because of the large amount of bandwidth used during the streaming, the Aruba mobility controller solution will need to support 10 Gbps links.

Which solution would cost-effectively meet this customer's requirements?

Which component uniquely defines the BSSID when implementing an employee SSID?

NewStellar has a main corporate campus in a business park with two adjacent buildings that are 150 feet apart (46 meters). This is an open campus with no obstructions between the two buildings Each building has three floors and each floor is 322 x 175 feet (98 x 53 meters) for 56,350 square feet (5,235 square meters) total, which results in a total of 338,100 feet (31,410 square meters) for the entire building space. The ceiling for each floor is 12 feet (3.6 meters) high with a drop-down ceiling at 10 feet (3 meters) The network architect has given one floor to analyze. Building 1 Floor 2, shown in the attached exhibit.

This floor has a central main corridor with washrooms, stairs, elevators and supply, and network cabinets. There are cubicles around the perimeter of the floor. The central part main corridor's dimensions contain 9,350 square feet (870 square meters).

The company has determined that Wi-Fi coverage will not include the central area of each floor, which includes the washrooms, stairs, elevators and supply and network cabinets. Based on a capacity design, approximately how many APs should a network architect add to each floor to plan the design in VisuaiRF?
