NSE5_SSE_AD-7.6 Dumps With Exact Questions and Answers

According to theSD-WAN 7.6 Core Administratorcurriculum and the diagnostic outputs shown in the exhibit, the reason traffic is steered toHUB1-VPN3instead of the expectedHUB1-VPN1(defined in SD-WAN rule ID 1) can be explained by two core routing principles in FortiOS:

Valid Route Requirement (Option A): In thediagnose sys sdwan service 4output (which corresponds to Rule ID 1), it shows the rule has membersHUB1-VPN1,HUB1-VPN2, andHUB1-VPN3. A key principle of SD-WAN steering is that for a member to be "selectable" by a rule, itmust have a valid route to the destinationin the routing table (RIB/FIB). If the routing table output (the third section of the exhibit) shows a route to 10.0.0.0/8 viaHUB1-VPN3butnotthroughHUB1-VPN1, the SD-WAN engine will skip HUB1-VPN1 entirely because it is considered a "non-reachable" path for that specific destination.

Policy Route Precedence (Option D): In the FortiOS route lookup hierarchy,Regular Policy Routes (PBR)are evaluatedbeforeSD-WAN rules. If an administrator has configured a traditional Policy Route (found underNetwork > Policy Routes) that matches traffic destined for 10.0.0.0/8 and specifiesHUB1-VPN3as the outgoing interface, the FortiGate will forward the packet based on that policy route and willnever evaluate the SD-WAN rulesfor that session. This "bypass" occurs regardless of whether the SD-WAN rule would have chosen a "better" link.

Why other options are incorrect:

Option B: While member configuration priority (cfg_order) is a tie-breaker in some strategies, the SD-WAN rule logic is only applied if the routing table allows it or if a higher-priority policy route doesn't intercept the traffic first.

Option C: Lower route priority (which means higher preference in the RIB) affects theImplicit Rule(standard routing). However, SD-WAN rules are designed tooverrideRIB priority for matching traffic. If HUB1-VPN1 was a valid candidate and no Policy Route existed, the SD-WAN rule would typically ignore RIB priority to enforce its own steering strategy.

According to theSD-WAN 7.6 Core Administratorcurriculum and theFortiOS 7.6 Administration Guide, setting common web-based services like Facebook and LinkedIn as destinations in an SD-WAN rule is primarily accomplished through theInternet Service Database (ISDB).

Internet Service vs. Application Control: In FortiOS, there is a distinction betweenInternet Services(which use a database of known IP addresses and ports to identify traffic at the first packet) andApplications(which require the IPS engine to inspect deeper into the packet flow to identify Layer 7 signatures).

SD-WAN Efficiency: Fortinet recommends using theInternet service fieldfor services like Facebook and LinkedIn in SD-WAN rules because it allows the FortiGate to steer the traffic immediately upon the first packet. If the "Application" signatures were used instead, the first session might be misrouted because the application is not identified until after the initial handshake.

GUI Configuration: As shown in the exhibit (image_b3a4c2.png), the "Destination" section of an SD-WAN rule includes anInternet servicefield by default. To steer Facebook and LinkedIn traffic, the administrator simply clicks the "+" icon in that field and selects the entries for Facebook and LinkedIn from the database.

Feature Visibility (Alternative): While youcanenable a specific "Application" field inSystem > Feature Visibility(by enabling "Application Detection Based SD-WAN"), this is typically used for less common applications that do not have dedicated ISDB entries. For the specific "applications" mentioned (Facebook and LinkedIn), they are natively available in theInternet servicefield, making Option B the most direct and common implementation.

Why other options are incorrect:

Option A: Licensing for application signatures is part of the standard FortiGuard services and is not a prerequisite specific only to "applications as destinations" in SD-WAN rules.

Option C: Standalone FortiGate devices fully support application-based and ISDB-based steering in SD-WAN rules.

Option D: While enabling feature visibility would add anadditionalfield for L7 applications, it is not a "must" for Facebook and LinkedIn, which are already accessible via the Internet Service field provided in the default GUI layout.
