The Sharpdome technology allows PTZ cameras to maintain a sharp image even when pointed above the horizon. This feature uses a specialized mechanical design and advanced image processing to ensure clear, undistorted images across the entire dome, including the critical area above the horizon. Axis Communications has integrated Sharpdome technology into several of their PTZ camera models, as explained in their product specifications and technical white papers.

" Motion blur is more prominent when an object moves perpendicularly (across) to the camera because it traverses more pixels per frame, compared to an object moving toward or away from the camera. "

— Axis Communications Academy, Network Video Fundamentals, 2022

" Perpendicular movement causes greater pixel change in each frame, resulting in more noticeable motion blur. "

— Axis Motion Blur Guide

" Dynamic range (often referred to as Wide Dynamic Range or WDR) is the difference between the lightest and darkest parts of a scene. A camera with high dynamic range can show details in both the highlights and shadows simultaneously. "

— Axis Communications Academy, Network Video Fundamentals, 2022

" Wide Dynamic Range (WDR) improves image quality in scenes with very bright and very dark areas by balancing light and dark areas. "

— Axis Communications, WDR Technology Overview

AXIS Site Designer offers various types of reports to assist in project planning and implementation. These include:

License keys report: Provides details on all license keys required for the project.

Installation report: Offers a comprehensive overview of installation details, including camera placements and configurations.

Bill of materials: Lists all the hardware and components needed for the project, ensuring that nothing is overlooked during the procurement process.

These reports help streamline the design, installation, and management of surveillance systems.

Day & Night cameras from Axis are designed to switch to a low-light mode by removing the IR-cut filter, making them sensitive to infrared light. In this mode, the cameras are most sensitive to IR light at a wavelength of 850 nm, which is commonly used in IR illuminators for night vision. This wavelength provides a good balance between visibility and discreetness, allowing the camera to capture clear images in low-light conditions. Axis Network Video documentation details the sensitivity range and performance characteristics of Day & Night cameras, emphasizing the importance of 850 nm wavelength for optimal night-time performance.

Top of Form

Bottom of Form

VAPIX® is an open API from Axis Communications that allows for the integration of Axis products with other system components. This openness facilitates the development of customized applications and solutions, making it easier for integrators to incorporate Axis products into broader security and surveillance systems, ensuring compatibility and flexibility. [Reference: Axis Communications - VAPIX API Documentation]

Top of Form

Bottom of Form

The AXIS T8414 Installation Display is a portable tool used for easy and efficient installation of network cameras. It can power up a PoE (Power over Ethernet) camera, allowing the installer to work without needing an additional power source. Additionally, the display can take snapshots, which helps in verifying the camera ' s field of view and focus during installation. It does not support accessing a camera ' s home page, resetting to factory defaults, or reading user documentation directly. For more details, refer to Axis Communications ' product manual for the AXIS T8414 Installation Display.

Top of Form

Bottom of Form

Ghost image occurs when the shutter time is too long. Long shutter times can cause moving objects to appear blurry or leave a " ghost " trail in the image, as the sensor is exposed to the scene for an extended period, capturing multiple positions of a moving object within a single frame.
