7% is the recommended minimum amount of Flash that a technical architect should specify when designing a Dell Unity XT 480 using the System Designer option of Sizer. This is because, Unity XT storage systems require a certain amount of flash storage to handle system-wide functions such as metadata, snapshots and other storage services.

controller-based D@RE has minimal performance impact for typical mixed workloads, and no impact to other Dell EMC Unity data services due to the level at which the encryption is performed, which is after all data services have been applied. https://www.delltechnologies.com/en-us/collaterals/unauth/white-papers/products/storage/h15090-dell-emc-unity-data-at-rest-encryption.pdf

A fully scaled-out Dell PowerStore T cluster requires at least two instances of PowerStore Manager to ensure high availability. This is because the PowerStore Manager provides a centralized management and monitoring interface for the cluster, and having multiple instances of it allows for redundancy in case one instance becomes unavailable.

https://downloads.dell.com/manuals/common/sc-series-performance-availability-best-practices-dell-emc-4024-bp-sc_en-us.pdf

(1.9 Sizing an SC Series array for performance requirements - pag.9)

FAST VP (Fully Automated Storage Tiering for Virtual Pools) and FAST Cache (Fully Automated Storage Tiering for Cache) are features that allow you to optimize the performance of your storage by automatically moving data between different storage tiers based on usage patterns. The SSD tier is used to store frequently accessed metadata, such as file system structures, directories, and inode tables, which are accessed frequently and are small enough to fit in the SSD cache. Keeping paged metadata on flash media improves the overall system performance, as it allows for faster access to the metadata, reducing the latency and the number of I/O operations needed to access it.

Dell PowerStore supports a variety of NAS protocols to provide file access to clients. These protocols include:

SMB (Server Message Block): This protocol is used to provide file and printer sharing on Windows-based systems.

NFSv3 (Network File System version 3): This is a standard protocol used to provide file access on UNIX-based systems.

NFSv4 (Network File System version 4): This is the latest version of the NFS protocol and it provides enhanced security and improved performance over previous versions.

FTP (File Transfer Protocol): This is a standard protocol used to transfer files between computers over a network.

SFTP (Secure File Transfer Protocol): This is an extension of the FTP protocol that provides secure file transfer using SSH (Secure Shell) encryption.

Diagram Description automatically generated

iSCSI offload is a network option that can be configured to provide the best iSCSI performance on a Dell Unity XT array. This option offloads iSCSI processing to the network adapter card, reducing the load on the host CPU and improving performance. With iSCSI offload enabled, the network adapter card can handle iSCSI processing tasks such as packet segmentation and reassembly, reducing the CPU overhead associated with iSCSI operations. Other options such as using a single VLAN for all traffic, configuring jumbo frames and disabling flow control may also help to improve iSCSI performance but iSCSI offload would provide the best results. It is important to note that configuring jumbo frames could have a positive impact on performance, but it also depends on the network infrastructure and the NICs support for it. Disabling flow control could cause issues on congested networks, so it's important to test it before disabling it.

Dell EMC Flash Storage Efficiency Guarantee Dell EMC promises our flash arrays will provide a logical usable capacity at least four times the usable physical capacity of your purchased drives —or we’ll give you more drives at no charge. https://www.delltechnologies.com/en-us/blog/dell-emc-flash-storage-efficiency/
