When provisioning a PostgreSQL cluster instance with an external load balancer in NDB, the administrator creates a software profile from a reference VM. The reference VM typically includes software like Patroni (for HA management), HAProxy (for internal load balancing), keepalived (for high availability IP management), and etcd (for distributed configuration). Since an external load balancer is used, the internal HAProxy can be omitted from the reference VM. NDB will rely on the external load balancer to distribute traffic, eliminating the need for HAProxy in the software profile, while the other components remain essential for cluster management.

Option A (Patroni) is incorrect because Patroni is required for PostgreSQL HA management.

Option B (HAProxy) is correct as it can be omitted when an external load balancer is configured.

Option C (keepalived) is incorrect because keepalived is needed for HA IP failover.

Option D (etcd) is incorrect because etcd is necessary for distributed configuration in the cluster.

This adjustment streamlines the profile for external load balancer use.

References

Nutanix Database Service (NDB) User Guide, Chapter 4: Managing Software Profiles, Section: Creating Software Profiles for HA Instances

Nutanix Certified Professional - Database Automation (NCP-DB) v7.5Blueprint, Section 4: Manage Database Software Profiles

NDB Multi-Cluster is a feature that allows multiple Nutanix clusters to share a common NDB service for database management and automation. NDB service consists of two components: NDB Server and NDB Agent. NDB Server is the central component that provides the web UI, REST API, and database orchestration logic. NDB Agent is the component that runs on each Nutanix cluster and communicates with the NDB Server to perform database operations.

When NDB Multi-Cluster is enabled on Cluster A, it becomes the primary cluster that hosts the NDB Server VM. Cluster B, which is registered with NDB, becomes a secondary cluster that hosts only the NDB Agent VM. Therefore, Cluster A has both NDB Server and NDB Agent, while Cluster B has only NDB Agent. This configuration allows Cluster B to leverage the NDB service running on Cluster A for database management and automation.

Nutanix Database Automation (NCP-DB) Course Details, Section 3.1: NDB Multi-Cluster Overview

Nutanix Database Automation (NCP-DB) Certification Details, Objective 3.1: Configure NDB Multi-Cluster

Nutanix Database Automation (NCP-DB) YouTube Playlist, Video 3.1: NDB Multi-Cluster Overview

To register a PostgreSQL database server VM with a database on NDB, the database data and log files must be located on a separate mount point from the operating system and the binary installation. This is because NDB uses the mount point as the identifier for the database server VM and the database. If the data and log files are on the same mount point as the operating system or the binary installation, NDB will not be able to recognize them as a valid database server VM or database. Therefore, the administrator should create a separate mount point for the data and log files and specify it during the registration process. References: Nutanix Database Automation (NCP-DB) Course Details, Nutanix Database Automation (NCP-DB) Certification Details, Nutanix Database Automation (NCP-DB) YouTube Playlist, [How to Allow Remote Access to PostgreSQL database], [5 Ways to Host PostgreSQL Databases] , [Starting the Database Server].

 In the context of Nutanix Database Automation (NCP-DB), a Super Admin has the authority to apply patch profiles. However, if a patch is marked as deprecated, even if it’s published, it cannot be applied. This is because deprecation is a status that indicates the patch is outdated or has been superseded by a newer version, and thus should not be used1. This behavior ensures that only the most up-to-date and secure patches are applied to the system, maintaining the integrity and security of the database environment1.

Nutanix Era is a database management system that provides API endpoints for automation and integration with external applications. These API calls are typically made over HTTPS for security, and the standard ports for HTTPS are 443 and 94401. Please note that the actual ports used can depend on the specific configuration of the Nutanix Era system. It’s always a good idea to check the system’s documentation or consult with the system administrator for the most accurate information.

An NDB Software Profile is a template of the OS and database engine that you can use to provision or clone database server VMs using NDB. To create a software profile, you need to upload an installer package for the database software that you want to use, such as SQL Server or Oracle. The installer package must be compatible with the OS image that you have registered with Prism Element. You do not need a database server VM registered with NDB, a patch file for the installed databases, or an OS image registered with Prism Element to create a software profile. Those are required for other tasks, such as creating a software profile version, registering a database server VM, or provisioning a database server VM.

 Nutanix Benefit 8: Integrated Self-service Database Management, Nutanix Support & Insights, section “NDB Software”

In NDB, database groups are used to manage multiple Microsoft SQL Server databases collectively, enabling centralized administration and protection policies. The statement "Databases within a database group can share multiple Time Machine configurations" is true. A Time Machine in NDB manages snapshots and log backups for recovery, and a database group can be associated with multiple Time Machine configurations to support different retention policies or recovery point objectives (RPOs) for the databases within the group. This flexibility allows tailored data protection strategies.

Other options are incorrect:

A. Microsoft recommends 35 databases within a single database group: There is no specific Microsoft recommendation for this limit; NDB imposes its own constraints based on performance and resource usage.

C. NDB supports one database group per database server VM or database server cluster: NDB allows multiple database groups per server or cluster, depending on configuration.

D. Databases within a database group must be all of the same size: NDB does not enforce uniform database sizes within a group.

Thus, the verified answer is B, reflecting NDB’s Time Machine flexibility.

Official Nutanix Database Automation References

Nutanix Database Management & Automation (NDMA) course, Module 3: Managing Database Instances, Lesson 3.6: Managing Database Groups.

Nutanix Certified Professional - Database Automation (NCP-DB) v7.5Knowledge Objectives, Section 3: Manage NDB Solutions, Objective 3.5: Configure Database Groups (applicable to v7.5).

Nutanix NDB Administration Guide: "Database Groups and Time Machine Configurations" section.

The exhibit shows an error during the provisioning of NDB from the Prism Central Marketplace, with a failure reason stating "IP not found" in the "EraService - Substrate Create" step. This indicates that the provisioning process could not assign or detect an IP address for the NDB instance, likely due to an unconfigured or missing IP address during deployment. To prevent this issue, the administrator should configure an IP address when deploying the application. This involves specifying a static IP or ensuring IP Address Management (IPAM) is properly set up to allocate an IP during the Prism Central Marketplace deployment wizard.

Other options are less directly relevant:

B. Import the proper image in the Prism Central: This ensures the correct NDB image is available but does not address the IP assignment issue.

C. Provide a subnet with IP Address Management: While useful, this is a broader configuration step and not the specific action needed during deployment.

D. Register NDB using the correct IP address: Registration occurs after deployment and does not prevent the initial IP assignment failure.

Thus, the verified answer is A, as configuring the IP address during deployment directly addresses the "IP not found" error.

Official Nutanix Database Automation References

Nutanix Database Management & Automation (NDMA) course, Module 2: Deploying and Configuring an NDB Solution, Lesson 2.2: Deploying NDB from Prism Central.

Nutanix Certified Professional - Database Automation (NCP-DB) v7.5Knowledge Objectives, Section 2: Deploy and Configure an NDB Solution, Objective 2.2: Deploy NDB (applicable to v7.5).

Nutanix NDB Installation Guide: "Deploying NDB via Prism Central Marketplace" section, emphasizing IP configuration.

The image provided shows the "Register Database Server VM" interface in NDB, which includes fields for registering a database server, including options for Windows and SQL Server credentials. When an administrator wants to register a database using a SQL Server User (instead of Windows credentials), the appropriate place to specify this user is in the "Connect to SQL Server Login" section. The interface includes a "User Name" field under this section, which becomes relevant after selecting the option to use a SQL Server User (typically indicated by a radio button or dropdown, though not fully visible in the image). This allows NDB to authenticate and manage the SQL Server instance using database-specific credentials rather than relying solely on Windows Administrator credentials.

Option A (In the Windows Administrator Name field) is incorrect because this field is intended for Windows OS-level credentials, not SQL Server-specific login credentials.

Option B (In the Login field after selecting SQL Server User) is correct as it aligns with the "Connect to SQL Server Login" section in the interface, where the SQL Server User can be specified after the appropriate option is selected.

Option C (Only via the command line registration option) is incorrect because the GUI provides a direct method to specify SQL Server credentials, as shown in the image.

Option D (By modifying the code in the API Equivalent section) is incorrect because the API Equivalent section is for reference and does not allow real-time modification; it’s meant to guide API-based automation, not manual registration.

The image confirms the presence of a "User Name" field under "Connect to SQL Server Login," supporting the use of a SQL Server User for registration.

References

Nutanix Database Service (NDB) User Guide, Chapter 2: Deploying and Configuring an NDB Solution, Section: Registering Database Server VMs

Nutanix Support & Insights, Knowledge Base Article: "Registering SQL Server VMs with NDB Credentials"

Nutanix Certified Professional - Database Automation (NCP-DB) v7.5Blueprint, Section 2: Deploy and Configure an NDB Solution

A custom NDB Software Profile is generated from a database server VM that has already been prepared and registered with NDB. The resulting profile captures the operating-system image and installed database software so that NDB can reproduce a standardized database server during provisioning. NDB does not dynamically retrieve all required operating-system and database binaries from YUM or APT repositories as part of profile creation. Out-of-the-box profiles are supplied and maintained by Nutanix and are not intended to be freely customized in place. A Software Profile is also substantially more than a text file containing runtime parameters; database configuration values belong to Database Parameters Profiles. Therefore, option D correctly describes the construction of a custom Software Profile from an existing NDB-managed database server. NDB User Guide—Software Profiles

================
