AVirtual Local Area Network (VLAN)is a logical separation of devices atLayer 2, even ifthose devices are connected to the same physical switch. Each VLAN forms itsown broadcast domain, and traffic cannot cross from one VLAN to anotherwithout Layer 3 routing.

Option Ais incorrect – devices on the same switch but in different VLANs still cannot communicate directly.

Option Bis incorrect – VLANs explicitlycreate separate broadcast domains.

Option Dis technically incorrect – communication is possible with the right setup.

Option Cis correct – to enable communication between different VLANs, arouteror aLayer 3 switchwith inter-VLAN routing capability is required.

This process is calledinter-VLAN routing, and it's a fundamental task in enterprise networks using VLANs.

In Nokia SR OS:

Aphysical interfacerefers to a physical port on the router (e.g., port 1/1/1).

It can be configured withIP addresses, associated with services (e.g., IES, VPRN), and connects to other routers or customer devices.

Systemandloopbackinterfaces arelogical interfaces, not physical.

Option D is FALSE, because a physical interfacecannotbe of type "system" or "loopback" — those arevirtual/logicalinterfaces in the Nokia router architecture.

In MPLS architecture, theIngress LER (Label Edge Router)is responsible for:

Pushing labelsonto unlabeled packets and injecting them into the MPLS domain.

Acting as thestarting point of the Label Switched Path (LSP).

From the diagram:

R1is thestarting point (Ingress LER)for both LSP A and LSP B.

R4is theEgress LER, which wouldpopthe labels at the end of the LSP.

So,R1 is responsible for label push (imposing)at the start of both LSPs.

Option A is correct– R1 pushes labels for both LSP A and LSP B.

Option Bis incorrect – R4 is an egress router, not ingress.

Option C/Dare incorrect – the LSPs both start at R1.

Tier 1 ISPs: Haveglobal reachabilityand exchange traffic via peering. Theydo not payfor transit.

Tier 2 ISPs: Purchasetransit services from Tier 1and provide transit to Tier 3 or other Tier 2 ISPs.

Tier 3 ISPs: Providelast-mileconnectivity to end users and donot provide transit services.

Option A is correct– Tier 1 and Tier 2provide transit services.

Spanning Tree Protocol (STP)is used specifically inEthernet Layer 2 networkstoprevent loopscaused byredundant paths.

STPdetects loops and blocks one or more redundant pathsto ensure there is aloop-free topologyin a bridged network.

STP dynamicallyrecalculates the topologyif a link fails, reactivating previously blocked paths.

Explanation of other options:

A. MPLS with LSPs:MPLS uses its own mechanisms for path management, such as RSVP or Segment Routing. STP is not applicable here.

C. OSPF with ECMP (Equal-Cost Multi-Path):OSPF is a Layer 3 protocol that inherently supports multiple paths without loops; STP is not involved.

D. eBGP (Exterior Border Gateway Protocol):Operates at Layer 3 for inter-AS communication; STP is not used in BGP routing.

Therefore,Option Bis correct, as STP is explicitly designed forLayer 2 Ethernet networkswithredundant paths.

A/31 subnetin IPv4 provides exactlytwo IP addresses(e.g., 192.168.1.0/31 → usable: 192.168.1.0 and 192.168.1.1). Traditionally, these would represent anetwork address and a broadcast address, butRFC 3021redefines /31 subnets forpoint-to-point links, such as router-to-router connections.

In a /31 subnet:

Broadcast address is not used.

Both IPs are treated as usable host addresses.

It'sideal for point-to-point links, saving address space.

This is widely supported andstandardized in Nokia IP and routing platforms.

BGP (Border Gateway Protocol)uses amulti-step decision processto select the best route among multiple paths. It doesnot use SPF or simple metrics like hop count.

Key BGP selection criteria include:

Local preference

AS path length

Origin type

MED (Multi-Exit Discriminator)

eBGP over iBGP

IGP metric to next hop

Option C is correct– BGP evaluatesmultiple attributesfor route selection.
