To resolve the IP conflict issue when an EC2 instance is powered on in a subnet also used by Nutanix NC2, the administrator should block or exclude the IP address used by the NC2 VM from being assigned to EC2 instances. This can be done by configuring the IP address management (IPAM) settings to ensure that the specific IP addresses allocated to the NC2 VMs are not used by EC2 instances, preventing IP conflicts and ensuring smooth operation of both environments.

Nutanix Cloud Clusters on AWS Deployment Guide

Nutanix Support and Insights

To deploy NC2 in AWS using an existing VPC, the following AWS resources should be configured beforehand:

NAT Gateway: This allows instances in the private subnet to connect to the internet or other AWS services, while preventing the internet from initiating connections with those instances.

Public and Private Subnets: These are necessary to segregate the network traffic. Public subnets provide a direct route to the internet gateway, while private subnets are used for internal resources that do not need direct access to the internet.

Nutanix Cloud Clusters on AWS Deployment Guide

Nutanix Support and Insights

The Nutanix Create Cluster wizard may not support selecting subnets that have both IPv4 and IPv6 CIDR blocks due to compatibility or configuration constraints.

When a subnet with both CIDR blocks is present, it can cause issues in the selection process during cluster creation, as the system might not be able to properly handle or recognize the dual-stack configuration.

Ensuring that the management subnet has only an IPv4 CIDR block, without an IPv6 CIDR block, could resolve this issue and allow for successful selection in the cluster creation wizard.

Refer to the Nutanix and AWS documentation on subnet configuration and requirements for NC2 cluster deployments, specifically addressing IPv4 and IPv6 compatibility and constraints.

For VDI workloads that require GPU acceleration, the g4dn.metal nodes are the appropriate choice. These instances are equipped with NVIDIA T4 GPUs, which are well-suited for graphics-intensive applications such as VDI workloads that need GPU acceleration. Other node types like AN36P, m6g.metal, or AN36 do not provide the necessary GPU capabilities.

Nutanix Support and Insights - GPU support in AWS

AVTEP (VXLAN Tunnel Endpoint) Gatewayshowing a status of " Down " indicates a connectivity or configuration failure within the control plane. In an NC2 environment, the gateway relies on consistent communication withPrism Central (PC)for management and synchronization, as well asNTP and DNSfor time-sync and name resolution. If the route tables in the AWS VPC are missing the necessary entries to reach these management services, the VTEP gateway will fail to initialize or maintain its heartbeat, resulting in a " Down " status. While on-premises reachability is important for traffic flow, the failure to create the extension entirely usually points to these missing internal routes that prevent the Nutanix software components from coordinating correctly within the cloud environment.

The alert indicates a potential issue with the VPC/Subnet settings, preventing the cluster nodes from contacting Nutanix services.

To resolve this, the administrator needs to ensure that the subnet 10.0.1.0/24, which is assigned for Bare metal hosts, has an outbound Internet connection.

This connection is necessary for the cluster nodes to communicate with external Nutanix services for updates, license validation, and other essential operations.

Verify that there are appropriate route tables and security group rules allowing outbound traffic to the Internet from the 10.0.1.0/24 subnet.

Ensure that there is either an Internet Gateway (IGW) attached to the VPC or a NAT Gateway configured if using private subnets.

Refer to the Nutanix documentation and AWS VPC configuration guides to ensure proper Internet connectivity and routing setups.

Integrating Flow Virtual Networking (FVN) into an NC2 cluster necessitates the creation of specific management and transit subnets to coordinate the overlay traffic. The administrator must ensure that aPrism Central subnet is configured on the Prism Elementside to facilitate the management link between the cluster nodes and the centralized management instance. Additionally, aTransit subnet must be configured on Prism Central. This transit subnet is critical because it houses the virtual routing components and gateways that manage traffic flow between different VPCs and the external network. By establishing these two subnets, the administrator provides the necessary control plane and data plane paths for the FVN overlay to communicate effectively with the underlying AWS infrastructure and the broader Nutanix management ecosystem.

WhenFlow Virtual Networking (FVN)is enabled for an NC2 cluster, Nutanix orchestrates the creation of aTransit VPCto handle traffic between the overlay and external networks. The core subnet created within this Transit VPC is namedoverlay-external-subnet-nonat. This subnet is critical as it serves as the entry and exit point for traffic that should not be subjected to address translation, such as traffic moving between the cloud overlay and an on-premises data center via a Transit Gateway or VPN. While administrators can manually add a NAT-enabled subnet later, the " nonat " variant is the primary default used to ensure that internal corporate communications remain transparent across the hybrid cloud boundary.

Upon creation, each node within an AWS NC2 cluster has3 Amazon Elastic Block Store (EBS)volumes attached.

These volumes are used for different purposes, such as operating system storage, Nutanix services, and user data storage.

The number of EBS volumes is designed to ensure adequate storage performance and capacity for the NC2 cluster ' s operations and workload demands.

Refer to the Nutanix documentation on NC2 cluster setup and AWS EBS volume configurations to confirm the details on the number and purpose of EBS volumes attached to each node.

For a VM to be accessible over the internet through a load balancer, the VM itself must have a public IP address.

In this case, the health check for the VM target is failing and the DNS returns a " NOT Found " message because web-1 does not have a public IP assigned.

Without a public IP, the load balancer cannot route traffic to web-1 from the internet.

Assigning a public IP to web-1 ensures that the VM can be accessed via the load balancer, resolving the connectivity issue.

Refer to the AWS documentation on network load balancers and public IP assignments, and Nutanix documentation on VM network configurations.
