According to section 5 of the exam blueprint guide 1 , one of the topics covered is live migration. Live migration is the process of moving a running VM from one host to another without any downtime or interruption of service. To perform live migration, there are some prerequisites that must be met, such as:

All AHV hosts have IP addresses in the same subnet

All VMs are configured for the same VLAN

The source and destination hosts have enough resources to accommodate the VM

The VM does not have any PCI devices attached

Automated live migration is a feature of Nutanix that allows the cluster to automatically move VMs from one host to another without any downtime, in order to optimize the performance and availability of the cluster.  According to the Nutanix documentation 1 , automated live migration can occur in the following scenarios:

Cluster resource hotspot: When a host or a group of hosts experience high resource utilization, such as CPU, memory, or network, the cluster can automatically migrate some VMs to other hosts with lower utilization, in order to balance the load and avoid performance degradation.

AOS upgrade: When upgrading the Nutanix software (AOS), the cluster can automatically migrate the VMs from the host that is being upgraded to another host in the same availability zone, in order to maintain the VM availability and minimize the impact of the upgrade process.

AHV host maintenance mode: When putting an AHV host into maintenance mode, the cluster can automatically migrate all the VMs from that host to another host in the same availability zone, in order to prepare the host for maintenance operations such as hardware replacement or firmware update.

When a VM is connected to a Nutanix managed network, the IP address is assigned when the VM is powered on. A Nutanix managed network is a network that is created and managed by Prism Central using IP address management (IPAM). IPAM allows Prism Central to automatically assign IP addresses to VMs from a pool of available addresses in a subnet.  IPAM also tracks the IP address usage and availability across clusters and networks 4 .

When a VM is connected to a Nutanix managed network, the administrator can choose one of the following assignment types for the IP address:

Assign Static IP: This option allows the administrator to manually specify a static IP address for the VM from the subnet range. The IP address will not change unless the administrator changes it.

Assign with DHCP: This option allows Prism Central to dynamically assign an IP address for the VM from the subnet range using DHCP. The IP address may change depending on the DHCP lease time and availability.

No Private IP: This option allows the administrator to skip assigning an IP address for the VM.  This option is useful for scenarios where the administrator wants to use an external IPAM solution or assign an IP address later 5 .

Regardless of the assignment type, the IP address is assigned when the VM is powered on. This is because Prism Central needs to communicate with the hypervisor (AHV or ESXi) to configure the virtual NIC (vNIC) of the VM with the IP address information.  This communication can only happen when the VM is in a powered on state 6 .

References:  4 :  IP Address Management - Prism Central Guide   5 :  Creating a New Report - Prism Central Guide   6 :  IP Address Assignment - AHV Networking Guide

A storage policy can be associated with a VM. A storage policy is a set of rules that define how data objects are stored and protected. It specifies the characteristics of storage, data protection, and data placement for virtual disks that are assigned to a VM. Subnets, catalogs, and categories are not associated with storage policies. https://portal.nutanix.com/page/documents/details?targetId=Prism-Central-Guide-vpc_2022_6:mul-cluster-storage-policy-summary-view-pc-r.html

According to the web search results, the two impacts on the cluster that will result from increasing the vCPU count on all of the VDI VMs are:

Increase CPU utilization%: CPU utilization is the percentage of time that a CPU is busy executing instructions 5 .  By increasing the vCPU count on all of the VDI VMs, the administrator will increase the demand for CPU resources on the cluster, which will increase the CPU utilization percentage 6 .

Increase CPU ready%: CPU ready is the percentage of time that a vCPU is ready to run but is waiting for a physical CPU to become available 5 .  By increasing the vCPU count on all of the VDI VMs, the administrator will increase the contention for physical CPU resources on the cluster, which will increase the CPU ready percentage 6 .  A high CPU ready percentage can indicate performance issues such as latency or slowdowns 5 .

data size for flash mode exceeds 25% of the SSD capacity  could cause the performance issues.  Flash mode is a feature that allows vDisks to be pinned to SSDs for faster access, but it has a limit of 25% of the SSD capacity per node .  If this limit is exceeded, some vDisks may be evicted from flash mode and cause disk latency 2 .

According to the  Nutanix Prism Central Guide , to configure a syslog server in Prism Central, you need to specify the transport protocol (TCP or UDP) and the IP address/port of the syslog server.
