FortiAnalyzer has two primary operating modes:Analyzer modeandCollector mode. Each mode serves specific purposes and has distinct capabilities.

Option A - Forwarding Logs to a Syslog Server in Collector Mode:

In Collector mode, FortiAnalyzer collects logs from Fortinet devices but does not process or analyze them. Instead, it forwards the logs to other FortiAnalyzer units in Analyzer mode or to specific storage locations. However, forwarding logs to a syslog server is not a function of Collector mode. Logs are generally stored or sent to other FortiAnalyzer devices.

Conclusion:Incorrect.

Option B - Default Mode is Collector Mode Unless Configured for HA:

When a FortiAnalyzer is initially set up, it runs in Collector mode by default unless it is configured as part of a High Availability (HA) setup, whichwould set it to Analyzer mode. Collector mode prioritizes log collection and storage rather than analysis, offloading analysis to other devices in the network.

Conclusion:Correct.

Option C - Report Creation and Editing in Collector Mode:

In Collector mode, FortiAnalyzer does not have the capability to create or edit reports. This mode is focused solely on log collection and forwarding, with analysis and report generation left to FortiAnalyzer units operating in Analyzer mode.

Conclusion:Incorrect.

Option D - Performance Improvement with Both Modes in Topology:

Deploying FortiAnalyzer devices in both Collector and Analyzer modes in a network topology can enhance performance. Collector mode devices handle log collection, reducing the workload on Analyzer mode devices, which focus on log processing, analysis, and reporting. This separation of tasks can optimize resource usage and improve the overall efficiency of log management.

Conclusion:Correct.

Conclusion:

Correct Answer:B. FortiAnalyzer runs in collector mode by default unless it is configured for HAandD. A topology with FortiAnalyzer devices running in both modes can improve their performance.

These answers correctly describe the functionality and default configuration of FortiAnalyzer operating modes, along with how a mixed-mode topology can enhance performance.

Comprehensive and Detailed Explanation From Exact Extract of knowledge of FortiAnalyzer 7.6 Study guide documents:

In the exhibit, theEvent Statusshown isUnhandled(Event Type: Web Filter; Severity: Critical). The FortiAnalyzer study guide definesUnhandledevents as events whose security risk has not been addressed and is therefore still active/open. Specifically, it states:“Unhandled: The security risk is considered open.”

This directly matches optionD.

The other options correspond to different statuses or actions:

Isolated/Containedapplies when the risk source is isolated (statusContained), notUnhandled.

Escalatedrefers to events moved/raised for further action (statusEscalated), notUnhandled.

Whether an incident was created cannot be concluded solely from the status “Unhandled” in the exhibit; the study guide ties incident creation to incident management workflows rather than equating “Unhandled” with an incident being created.

The command diagnose sql statussqlreportd is used in FortiAnalyzer to obtain specific information about the SQL reporting process and caching status. Here’s what this command accomplishes and an analysis of each option:

Command Functionality:

sqlreportd is the FortiAnalyzer daemon responsible for managing SQL-based reporting processes.

The diagnose sql status sqlreportd command provides information on active SQL query connections and thehcache(historical cache) status, which helps in monitoring and troubleshooting SQL report generation.

Option Analysis:

Option A - To View a List of Scheduled Reports:

This option is incorrect because the command does not list scheduled reports. Instead, it focuses on SQL reporting processes and cache details.

Option B - To List the Current SQL Processes Running:

While the command may show active SQL connections, its primary focus is not a detailed list of all SQL processes but rather the connections and cache status for reporting.

Option C - To Display the SQL Query Connections and hcache Status:

This is correct. The command specifically provides information on SQL query connections related to the reporting process (sqlreportd) and displays thehcachestatus.

Option D - To Identify the Database Log Insertion Status:

This is incorrect. The command does not provide details on log insertion status. Log insertion status is typically monitored through different diagnostic commands focused on database processes and log handling.

Conclusion:

Correct Answer:C. To display the SQL query connections and hcache status

This command is used to monitor SQL reporting activities and cache status, aiding in the analysis of report generation performance and connection health.

In FortiAnalyzer's incident management system, analysts have the option to manually manage incidents, which includes attaching relevant reports to an incident for further investigation and documentation. This feature allows analysts to consolidate information, such as detailed reports on suspicious activity, into an incident record, providing a comprehensive view for incident response.

Let's review the other options to clarify why they are incorrect:

Option A: You can manually attach generated reports to incidents

This is correct. FortiAnalyzer allows analysts to manually attach reports to incidents, which is beneficial for providing additional context, evidence, or analysis related to the incident. This functionality is part of the incident management process and helps streamline information for tracking and resolution.

Option B: The status of the incident is always linked to the status of the attached event

This is incorrect. The status of an incident on FortiAnalyzer is managed independently of the status of any attached events. An incident can contain multiple events, each with different statuses, but the incident itself is tracked separately.

Option C: Severity incidents rated with the level High have an initial service-level agreement (SLA) response time of 1 hour

This is incorrect. While incidents have severity levels, specific SLA response times are typically set according to the organization’s incident response policy, and FortiAnalyzer does not impose a default SLA response time of 1 hour for high-severity incidents.

Option D: Incidents must be acknowledged before they can be analyzed

This is incorrect. Incidents on FortiAnalyzer can be analyzed even if they are not yet acknowledged. Acknowledging an incident is often part of the workflow to mark it as being actively addressed, but it is not a prerequisite for analysis.

In FortiAnalyzer,archive logsrefer to logs that have been compressed and stored to save space. This process involves compressing the raw log files into the .gz format, which is a common compression format used in Fortinet systems for archived data. Archiving is essential in FortiAnalyzer to optimize storage and manage long-term retention of logs without impacting performance.

Let’s examine each option for clarity:

Option A: Logs that are indexed and stored in the SQL database

This is incorrect. While some logs are indexed andstored in an SQL database for quick access and searchability, these are not classified asarchive logs. Archived logs are typically moved out of the database and compressed.

Option B: Logs a FortiAnalyzer administrator can access in FortiView

This is incorrect becauseFortiViewprimarily accesses logs that are active and indexed, not archived logs. Archived logs are stored for long-term retention but are not readily available for immediate analysis in FortiView.

Option C: Logs compressed and saved in files with the .gz extension

This is correct. Archive logs on FortiAnalyzer are stored in compressed .gz files to reduce space usage. This archived format is used for logs that are no longer immediately needed in the SQL database but are retained for historical or compliance purposes.

Option D: Logs previously collected from devices that are offline

This is incorrect. Although archived logs may include data from devices that are no longer online, this is not a defining characteristic of archive logs.
