To combine the lines to appear as shown in the second chart, you should set Discount to Dual Axis. Dual Axis is a feature that allows you to show two measures on two separate axes on one chart. You can create a dual axis by right-clicking on a measure on any shelf and selecting Dual Axis from the menu. This will create two axes on one chart and synchronize their scales.

In this case, you want to show Profit and Discount on two separate axes on one chart. You can right-click on Discount on any shelf and select Dual Axis from the menu. This will create a dual axis chart that shows Profit and Discount as two lines with different colors.

The other options are not correct for this scenario. Dragging Discount to Color on the Marks card will change the color of Profit based on Discount, but it will not show two lines. Converting Discount to Discrete will change Discount from a green pill to a blue pill, but it will not affect how it appears on the chart. Dragging Discount to Columns shelf will create two separate charts for Profit and Discount, but it will not combine them. References: https://help.tableau.com/current/pro/desktop/en-us/multiplemeasures.htm https://help.tableau.com/current/pro/desktop/en-us/multiplemeasures_dualaxes.htm

To create a boolean calculated field to place on the data source filter, you should use the formula USERNAME() = [Tableau_user]. This formula will return TRUE if the current Tableau user name matches the value in the Tableau_user field, and FALSE otherwise. You can use this formula as a data source filter by dragging it to the Filters shelf and selecting TRUE from the menu. This will filter the data to show only the rows that are relevant to the specific Tableau user.

The other options are not correct for this scenario. NAME([Tableau_user]) is not a valid function in Tableau. ISFULLNAME([Tableau_user]) = USERNAME() is not a valid expression in Tableau. ‘S’ + STR([Sales]/1000) is not a boolean expression, but a string expression that converts sales to thousands with a prefix of “S”. References: https://help.tableau.com/current/pro/desktop/en-us/filtering_datasource.htm https://help.tableau.com/current/pro/desktop/en-us/functions_functions_logical.htm#USERNAME https://help.tableau.com/current/pro/desktop/en-us/calculations_calculatedfields.htm

In Tableau, the USERNAME() function returns the username of the user who is currently logged in. To create a filter that only shows data relevant to the logged-in Tableau user, a boolean calculated field can be created to compare the current username with the usernames listed in the Tableau_User_Name field of the dataset. Therefore, the correct formula for this filter is USERNAME() = [Tableau_USER_NAME], which will return true for rows where the Tableau_User_Name matches the current user's username.

we need to create a calculated field that displays the count of returns only for the first year in the table. To do this, we can use the following formula:

IF FIRST () = 0 THEN COUNT (Returns) END

This formula uses the FIRST () function, which returns the number of rows from the current row to the first row in the partition. If the current row is the first row, then FIRST () returns 0. The IF statement checks if this condition is true, and if so, it returns the count of returns for that row. Otherwise, it returns NULL.

To complete the formula in the calculated field, you should select the following options from the drop-down menus:

FIRST ()

0

COUNT (Returns)

https://help.tableau.com/current/pro/desktop/en-us/functions_functions_date.htm

To add the Sales by State sheet in a Show/Hide button to the right side of the dashboard, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the sales dashboard.

Click on the sales dashboard tab at the bottom of the workbook to open the dashboard. You will see a dashboard that shows various charts and filters related to sales data.

Drag Sales by State from the Sheets pane to the right side of the dashboard. This will add the sheet as a floating element on the dashboard. You can resize and position it as you like.

Right-click on Sales by State and select Add Show/Hide Button from the menu. This will add a button that allows you to show or hide the sheet on the dashboard. You can customize the appearance and behavior of the button by clicking on it and using the options on the Marks card.

Optionally, you can drag a vertical layout container from the Objects pane to the right side of the dashboard and place Sales by State and its button inside it. This will help you organize your dashboard elements and align them neatly.

To split the Customer Name field into two fields named First Name and Last Name, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that uses the Superstore data source.

Go to the Data Source tab at the bottom of the workbook to see the data source page. You will see a table that shows the fields and values from the Superstore data source.

Right-click on Customer Name in the table and select Split from the menu. This will split the field into two fields based on a separator, which is a space by default. You will see two new fields named Customer Name - Split 1 and Customer Name - Split 2 in the table.

Right-click on Customer Name - Split 1 and select Rename from the menu. Type First Name as the new name and press Enter. This will rename the field as First Name.

Right-click on Customer Name - Split 2 and select Rename from the menu. Type Last Name as the new name and press Enter. This will rename the field as Last Name.

To filter the table to show the members of the Top10 set and the Bottom10 set, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the Disciplines worksheet.

Click on the Disciplines tab at the bottom of the workbook to open the worksheet. You will see a table that shows the disciplines, sales, and profit for each salesperson.

Click on the drop-down arrow next to Salesperson on the Filters shelf. This will open a menu that allows you to filter by different criteria.

Select Set from the menu. This will show you the sets that are available for the Salesperson field. You will see Top10 and Bottom10 as two sets that have been created based on the sales ranking.

Check the boxes next to Top10 and Bottom10. This will filter the table to show only the members of these two sets. You can also click on All to deselect all other values.

Click OK to apply the filter. You will see that the table now shows 20 rows, 10 for each set.

To modify the bar chart to show the percentage of sales for each Subcategory within every Category, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the CategoryPercentage worksheet.

Click on the CategoryPercentage tab at the bottom of the workbook to open the worksheet. You will see a bar chart that shows the total sales for each Subcategory across all Categories.

Right-click on Sales on the Columns shelf and select Add Table Calculation from the menu. This will open a dialog box that allows you to apply a calculation to your measure.

Select Percent of Total from the Calculation Type drop-down list. This will calculate the percentage of sales for each Subcategory out of the total sales for all Subcategories.

Select Category from the Compute Using drop-down list. This will calculate the percentage of sales for each Subcategory within every Category, instead of across all Categories. The total percentage for every Category will be 100%.

Click OK to apply the table calculation. You will see that the bar chart now shows the percentage of sales for each Subcategory within every Category.
