Static routing is a form of routing that occurs when a router uses a manually-configured routing entry, rather than information from dynamic routing traffic 1. Static routing has some advantages, such as simplicity, low overhead, and full control, but it also has some disadvantages, such as:

•Manual reconfiguration: Static routes require manual effort to configure and maintain. This can be time-consuming and error-prone, especially in large networks with many routes. If there is a change in the network topology or a link failure, the static routes need to be updated manually by the network administrator 23.

•Single point of failure: Static routing is not fault tolerant. This means that if the path used by the static route stops working, the traffic will not be rerouted automatically. The network will be unreachable until the failure is repaired or the static route is changed manually. Dynamic routing, on the other hand, can adapt to network changes and find alternative paths 23.

OSPF is a link-state routing protocol that requires all routers in the same domain to maintain a map of the network. This map is called the link-state database (LSDB) and it contains information about the topology and the state of each link. Each router independently calculates the shortest path to every destination in the network using the Dijkstra algorithm. OSPF routers exchange routing information by flooding link-state advertisements (LSAs) to their neighbors. LSAs are acknowledged by the receivers to ensure reliable delivery12. References:

What Is OSPF? Understanding Network Protocols By WireX Systems

Routing Protocols Overview - Global Knowledge

List three advantages of serverless computing over

CaaS: - Reduce costs - Increase agility - Reduce operational overhead

To maximize the use of a network address, the administrator should use the subnet that can accommodate the required number of hosts with the least amount of wasted IP addresses. The subnet mask determines how many bits are used for the network portion and the host portion of the IP address. The more bits are used for the network portion, the more subnets can be created, but the fewer hosts can be assigned to each subnet. The formula to calculate the number of hosts per subnet is

2(32−n)−2

, where

n

is the number of bits in the network portion of the subnet mask. For example, a /30 subnet mask has 30 bits in the network portion, so the number of hosts per subnet is

2(32−30)−2=2

A /25 subnet mask has 25 bits in the network portion, so the number of hosts per subnet is

2(32−25)−2=126

The subnet 192.168.6.0/25 can accommodate 126 hosts, which is enough for the network with 120 hosts. The subnet 192.168.6.168/30 can only accommodate 2 hosts, which is not enough. The subnet 192.168.6.160/29 can accommodate 6 hosts, which is also not enough. The subnet 192.168.6.128/27 can accommodate 30 hosts, which is enough, but it wastes more IP addresses than the /25 subnet. Therefore, the best option is B. 192.168.6.0/25. References:

Getting Started: Layer 3 Subinterfaces - Palo Alto Networks Knowledge Base

DotW: Multiple IP Addresses on an Interface - Palo Alto Networks Knowledge Base

Configure NAT - Palo Alto Networks | TechDocs

Cloud Security Posture Management (CSPM), including Prisma Cloud’s offering, continuously monitors all cloud resources — such as compute instances, storage, network configurations, and identities — to detect misconfigurations, vulnerabilities, and potential threats in near real time.

A botnet is a network of computers or devices that are infected by malware and controlled by a malicious actor, known as the botmaster or bot-herder. The botmaster uses a command and control (C2) server or channel to send instructions to the bots and receive information from them. The C2 communication is essential for the botmaster to maintain control over the botnet and use it for various malicious purposes, such as launching distributed denial-of-service (DDoS) attacks, stealing data, sending spam, or mining cryptocurrency. Therefore, the key to “taking down” a botnet is to prevent the bots from communicating with the C2 server or channel. This can be done by disrupting, blocking, or hijacking the C2 communication, which can render the botnet ineffective, unstable, or inaccessible. For example, security researchers or law enforcement agencies can use techniques such as sinkholing, domain name system (DNS) poisoning, or domain seizure to redirect the bot traffic to a benign server or a dead end, cutting off the connection between the bots and the botmaster. Alternatively, they can use techniques such as reverse engineering, decryption, or impersonation to infiltrate the C2 server or channel and take over the botnet, either to disable it, monitor it, or use it for good purposes. References:

What is a Botnet? - Palo Alto Networks

Botnet Detection and Prevention Techniques | A Quick Guide - XenonStack

Botnet Mitigation: How to Prevent Botnet Attacks in 2024 - DataDome

What is a Botnet? Definition and Prevention | Varonis

Cortex XDR is a detection and response platform that natively integrates network, endpoint, and cloud data to stop sophisticated attacks. A key benefit of Cortex XDR is that it acts as a safety net during an attack while patches are developed. Cortex XDR uses machine learning and behavioral analytics to detect and validate threats, and automatically reveals the root cause of alerts to speed up investigations. Cortex XDR also enables flexible and rapid response actions to contain and remediate threats across the environment. References: Cortex XDR- Extended Detection and Response - Palo Alto Networks, What is Cortex XDR | Palo Alto Networks, Cortex XDR Datasheet - Palo Alto Networks

Pharming is an attack that redirects traffic from a legitimate website to a malicious fake website, typically by corrupting the DNS system or modifying host files, with the intent of stealing user credentials or sensitive data.

A layer 2 switch will break up collision domains but not broadcast domains. To break up broadcast domains you need a Layer 3 switch with vlan capabilities.

2G/2.5G: 2G connectivity remains a prevalent and viable IoT connectivity option due

to the low cost of 2G modules, relatively long battery life, and large installed base of

2G sensors and M2M applications.

○ 3G: IoT devices with 3G modules use either Wideband Code Division Multiple Access

(W-CDMA) or Evolved High Speed Packet Access (HSPA+ and Advanced HSPA+) to

achieve data transfer rates of 384Kbps to 168Mbps.

○ 4G/Long-Term Evolution (LTE): 4G/LTE networks enable real-time IoT use cases, such

as autonomous vehicles, with 4G LTE Advanced Pro delivering speeds in excess of

3Gbps and less than 2 milliseconds of latency.

○ 5G: 5G cellular technology provides significant enhancements compared to 4G/LTE

networks and is backed by ultra-low latency, massive connectivity and scalability for

IoT devices, more efficient use of the licensed spectrum, and network slicing for

application traffic prioritization.
