Let ' s break it down step by step based on Huawei ' s routing protocol behavior:

R1 imports the direct route 10.1.1.0/24 into OSPF .

This route is advertised by R1 to R2 and R3 via OSPF .

Both R2 and R3 are running IS-IS , and bidirectional route redistribution is configured between OSPF and IS-IS.

R2 and R3 both re-advertise the OSPF-learned route into IS-IS and then potentially re-learn it back from the IS-IS domain, causing redistribution loops unless properly controlled.

Now, the question focuses on R3’s routing table :

R3 already learns the route directly via OSPF from R1.

It also learns the same route again via IS-IS from R2 (looped back due to bidirectional redistribution).

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“OSPF ASE routes are assigned a default preference of 150. If a route is redistributed from another protocol (like IS-IS) into OSPF, and then re-learned, it is considered an ASE route.” (Chapter: OSPF Advanced Features – Section: Route Redistribution Behavior)

Comprehensive and Detailed Step-by-Step Explanation:

Session Creation in Firewalls:

Firewalls create session entries for packets requiring stateful inspection (e.g., TCP, UDP, ICMP, and GRE).

Subsequent fragments of large packets do not require new sessions. Instead, they are processed based on the session created for the first fragment.

Correct Option:

C (Subsequent Fragment): Does not trigger a new session entry as it belongs to an existing session.

By default, BGP does not automatically summarize imported routes. Route summarization must be explicitly configured using the summary or similar commands ​.

 Understanding BGP Route Summarization :

In Border Gateway Protocol (BGP), route summarization is a technique used to aggregate multiple specific prefixes into a broader summary prefix. This reduces the size of routing tables and improves routing efficiency.

Summarization helps to hide unnecessary details from other parts of the network while still maintaining connectivity.

Comprehensive and Detailed In-Depth Explanation:

STP (Spanning Tree Protocol) BPDUs do not contain an explicit port role field . Instead, roles are determined indirectly.

RSTP (Rapid Spanning Tree Protocol) modifies BPDU structure by using the Flags field to indicate:

Port roles (Root, Designated, Alternate, Backup)

Proposal/Agreement (P/A) handshake mechanism

The correct field that specifies the port role in RSTP BPDUs is Flags .

???? Reference: Huawei HCIA-Datacom Study Guide, RSTP BPDU Structure and Flags Field.

By default, Huawei firewalls create security zones named untrust , dmz , trust , and local . These zones facilitate security policies for inbound, outbound, and inter-zone traffic control ​.

Comprehensive and Detailed In-Depth Explanation:

IP Prefix lists are used to filter routes based on prefix and mask length .

The optional parameters include:

Index of the prefix list → Specifies priority/order (Optional).

Shortest mask length to be matched → Defines the minimum subnet mask (Optional).

Longest mask length to be matched → Defines the maximum subnet mask (Optional).

Mask length (D) is mandatory because it specifies the exact prefix length being matched.

???? Reference: Huawei HCIA-Datacom Study Guide, Configuring Prefix Lists for Route Filtering.

In OSPF, Database Description (DD) packets are used during the database synchronization process. In the first DD packet a router sends during neighbor establishment, three control bits are set:

I bit (Initial) = 1 → This indicates that the DD packet is the first in the sequence.

M bit (More) = 1 → This means more DD packets will follow.

MS bit (Master/Slave) = 1 → Set by the router assuming the master role in the exchange process.

Setting all three bits to 1 is a standard part of the DD exchange initiation.

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“In the initial DD packet, the I, M, and MS bits are set to 1 by the master router initiating database exchange.”

(Chapter: OSPF Operation Mechanism – Section: Neighbor State Machine)

The asbr-summary command is executed in the global OSPF view to summarize external routes. The abr-summary command is executed in the OSPF area view to summarize routes between areas. By default, the advertise parameter is enabled unless explicitly overridden by the not-advertise option ​.
