The exhibit refers to the Cisco Prime Infrastructure’s planning mode feature, which is a tool used for designing and planning wireless networks. The planning mode allows network administrators to input floor plans and simulate access point placement for optimal coverage. It does not require a special license; it is part of the Cisco Prime Infrastructure’s base functionalities. Planning mode does not necessarily present the recommended number of APs; instead, it allows users to manually place potential APs on a map to predict coverage areas. While synchronization with controllers may enhance functionality, it is not strictly necessary for planning mode to operate.

References  := (CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice)

IEEE 802.11ac Wave 2 APs are backward compatible with 802.11a/n clients, allowing these devices to connect and communicate with the newer APs, albeit at their respective maximum supported speeds.

Voice services on a wireless network require a strong and stable signal, as well as low interference and retransmission rates. An RSSI (Received Signal Strength Indicator) of at least -67 dBm is considered the minimum for acceptable voice quality, and -65 dBm is even better, providing a buffer for signal fluctuation. A noise floor of -87 dBm would be too high and could interfere with signal clarity. Retransmission rates should be kept as low as possible; 15% or below is a good target to ensure efficient communication.

 Fast Transition (FT), also known as IEEE 802.11r, is the key-caching mechanism that must be configured to speed up the reauthentication delays on the wireless infrastructure.  FT allows for rapid re-authentication when roaming between access points, reducing the time required for re-establishing security keys and thus speeding up the overall process 2 .

To reduce full authentication requests and optimize roaming, enabling Cisco Centralized Key Management (CCKM) on the voice SSID is effective. CCKM allows for fast re-authentication during roaming, which is beneficial for voice applications. Adding APs to a FlexConnect group helps manage APs in remote branches more efficiently.

Typically, a Cisco workgroup bridge can support up to 20 wired client connections. This allows for a reasonable number of devices to be connected while maintaining performance.

When using the Cisco Prime Infrastructure Planning Tool for deploying a Greenfield 802.11n network with data, voice, location awareness, and APs equipped with WSSI modules, selecting ‘Voice’ will ensure that the tool accounts for the additional bandwidth requirements of voice applications which have strict QoS requirements. Choosing ‘Location’ will allow the tool to consider the need for more precise location tracking capabilities which typically require additional APs for triangulation purposes.  References  := CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice
