Task 1(a): Develop the cloud-init Script:

Create a compute instance pbt_cloud_init_vm_01 with the following properties:

Shape: VM.Standard.A1.Flex instance with 1 OCPU and 6 GB memory

Image: Oracle Linux 8

Placement: Use any of the availability domains

Network:

Place in the public subnet Cloud-Init Challenge SNT

Assign a public IPv4

Use the SSH public key

Add a cloud-init script and perform the following:

Use yum or dnf to install httpd.

Use systemctl to enable and start httpd

Open the firewall to http:

sudo firewall-offline-cmd --add-service=http

systemctl restart firewalld

Mark Complete

Task 1(b): Use cloud-init to Configure Apache on Instances in an Autoscaling Instance Pool:

You ' re deploying an Apache-based web application on OCI that requires horizontal autoscaling.

To  configure instances upon provisioning, write a cloud-init script for  Oracle Linux 8 that installs and enables Apache (httpd), and opens the  firewall for HTTP on TCP port 80. Create an instance configuration and  include the cloud-init script in it. Use this instance configuration to  create an instance pool and autoscaling configuration.

Task 2: Create an Autoscaling Instance Pool Including the cloud-init Script:

Create an instance configuration named pbt_cloud_init_config_01 with the following properties:

Shape: VM.Standard.A1.Flex instance with 1 OCPU and 6 GB memory

Image: Oracle Linux 8

Placement: Use any of the availability domains

Network:

Place in the public subnet Cloud-Init Challenge SNT

Assign a public IPv4

Use the SSH public key

Attach the cloud-init script created in Task 1

Create  an instance pool named pbt_cloud_init_pool_01 with one instance by  using the instance configuration pbt_cloud_init_config_01

Create and attach an autoscaling configuration named pbt_cloud_autoscaling_config_01 with the following settings:

Metric-based autoscaling

Cooldown: 300 second

Performance metric: CPU utilization

Scale-out rule:

Operator: Greater than ( > )

Threshold: 75%

Number of instances to add: 1

Scale-in rule:

Operator: Less than ( < )

Threshold: 25%

Number of instances to remove: 1

Scaling limits:

Minimum number of instances: 1

Maximum number of instances: 2

Initial number of instances: 1

Task 1: Develop the cloud-init script

In the main menu, go to  Compute > Instances  and click  Create an Instance

In the instance creation menu, enter the following details

   a. Name:  Provide name given in the instructions

   b. Compartment: Use the  assigned compartment

   c. Placement: Use any of the availability domains

   d. Image: Oracle Linux 8

   e. Shape: VM.Standard.A1.Flex instance with 1 OCPU and 6 GB memory

   f. Network:

       i. Place in the public subnet

      ii. Assign a public IPv4

   g. SSH keys: Upload or paste the provided SSH public key

   h. Boot volume:  Leave as default

   i. Under advanced options, add the following cloud-init script:

#!/bin/shsudo dnf install httpd --assumeyes --quietsudo systemctl enable httpdsudo systemctl start httpdsudo firewall-offline-cmd --add-service=httpsystemctl restart firewalld

   j. Create the instance.

Task 2: Create an autoscaling instance pool including the cloud-init script

1. In the main menu, go to  Compute   >   Instance Configurations . Click  Create instance configuration .

  a. In the instance configuration creation menu, enter the same details as before:

  b. Name:  Provide name given in the instruction/if not specified provide any name

  c. Compartment:  Assigned compartment

  d. Placement: Use any of the availability domains

  e. Image: Oracle Linux 8

  f. Shape: VM.Standard.A1.Flex instance with 1 OCPU and 6 GB memory

  g. Network:

     i. Place in the public subnet

    ii. Assign a public IPv4

   h. SSH keys: Upload or paste the provided SSH public key

   i. Boot volume:  Leave as default

   j. Under advanced options, add the following cloud-init script:

#!/bin/shsudo dnf install httpd --assumeyes --quietsudo systemctl enable httpdsudo systemctl start httpdsudo firewall-offline-cmd --add-service=httpsystemctl restart firewalld

   k. Create the instance configuration.

Task 2:  In the main menu, go to  Compute > Instance Pools . Click  Create instance pool.

Enter the following details:

a. Name:  Provide name given in the instruction/if not specified provide any name

b. Compartment:  Assigned compartment

c. Instance configuration: Created in last step

d. Number of instances: 1

e. Select any availability domain

f. Leave fault domain unselected

g. Primary VNIC:  Provided VCN in the instructions

h. Subnet:  Public subnet

i. Do not attach a load balancer

j. Create the instance pool

Task 3:  In the main menu, go to  Compute > Autoscaling Configurations . Click  Create autoscaling configuration  and enter the following details:

a. Name:  Provide name given in the instruction/if not specified provide any name

b. Compartment:  Assigned compartment

c. Instance Pool:  Created in last step

d. Select Metric-based autoscaling

e. Autoscaling policy name:  Does not matter

f. Cooldown: 300 seconds

g. Performance metric: CPU utilization

h. Scale-out rule:

i. Operator: Greater than ( > )

ii. Threshold: 75%

iii. Number of instances to add: 1

i. Scale-in rule:

i. Operator: Less than ( < )

ii. Threshold: 25%

iii. Number of instances to remove: 1

j. Scaling limits:

i. Minimum number of instances: 1

ii. Maximum number of instances: 2

iii. Initial number of instances: 1

k. Create the autoscaling configuration.

Task 1

Write  a policy statement to enable Network-Admins to create and destroy  network-related resources, such as VCNs, subnets, gateways, and so on in  the Network compartment.

Solution- Policy Statement:

allow Network-Admins to manage virtual-network-family in compartment Common-Infra:Network

Task 2

Write  policy statements to enable E-Comm-Admins to provision and destroy  compute instances in the E-Comm compartment by using networking  resources in the Network compartment.[Write one policy per given text  box]

Solution- Policy Statement:

allow E-Comm-Admins to manage instance-family in compartment Applications:E-Comm allow E-Comm-Admins to use virtual -network-family in compartment Common-Infra:Network

Task 3

Write  a policy statement to enable SCM-Admins to provision, destroy, and back  up block volumes in the SCM compartment—but only in Phoenix and London.

Solution- Policy Statement:

allow SCM-Admins to manage volume-family in compartment Applications:SCM where any{request.region= ' phx ' ,request.region= ' lhr ' }

Create a Terraform Folder and File in Code Editor:

You’ll create a folder and file to hold your Terraform scripts.

1.  Log in to your tenancy in the Cloud Console and open the Code Editor,  whose icon is at the top-right corner, to the right of the CLI Cloud  Shell icon.

2. Expand the Explorer panel with the top icon on the left panel. It looks like two overlapping documents.

3. Expand the drop-down for your home directory if it isn’t already expanded. It’s okay if it is empty.

4. Create a new folder by clicking  File , then  New Folder , and name it terraform-vcn .

5. Create a file in that folder by clicking  File , then  New File , and name it vcn.tf .  To make Code Editor, create the file in the correct folder, click the folder name in your home directory to highlight it.

6. First, you’ll set up Terraform and the OCI Provider in this directory. Add these lines to the file:

terraform {required_providers {oci = {source = " oracle/oci " version = " > =4.67.3 " }}required_version = " > = 1.0.0 " }

7. Save the changes by clicking  File , then  Save .

8. Now, run this code. Open a terminal panel in Cloud Editor by clicking  Terminal , then  New Terminal .

9. Use pwd to check that you are in your home directory.

10. Enter ls and you should see your terraform_vcn directory.

11. Enter cd terraform_vcn/ to change to that directory with.

12. Use terraform init to initialize this directory for Terraform.

13. Use ls -a and you should see that Terraform created a hidden directory and file.

Create and Destroy a VCN Using Terraform

You’ll create a Terraform script that will launch a VCN and subnet.

You’ll  then alter your script and create two additional files that will apply a  compartment OCID variable to your Terraform script.

Write the Terraform

1. Add the following code block to your Terraform script to declare a VCN, replacing  < your_compartment_ocid >  with the proper OCID. The only  strictly  required parameter is the compartment OCID, but you’ll add more later.

If you need to retrieve your compartment OCID, navigate to  Identity & Security , then  Compartments . Find your compartment, hover the cursor over the OCID, and click  Copy .

resource " oci_core_vcn " " example_vcn " {compartment_id = " < your_compartment_ocid > " }

This snippet declares a  resource block  of type  oci_core_vcn . The label that Terraform will use for this resource is  example_vcn .

2.  In the terminal, run terraform plan, and you should see that Terraform  would create a VCN. Because most of the parameters were unspecified,  terraform will list their values as “(known after apply).” You can  ignore the “-out option to save this plan” warning.

Note  that terraform plan parses your Terraform configuration and creates an  execution plan for the associated stack, while terraform apply applies  the execution plan to create (or modify) your resources.

3. Add a display name and CIDR block (the bolded portion) to the code. Note that we want to set the  cidr_blocks  parameter, rather than  cidr_block  (which is deprecated).

resource " oci_core_vcn " " example_vcn " {compartment_id = " < your_compartment_ocid > " display_name = " VCN-01 " cidr_blocks = [ " 10.0.0.0/16 " ]}

4. Save the changes and run terraform plan again. You should see the display name and CIDR block reflected in Terraform’s plan.

5. Now add a subnet to this VCN. At the bottom of the file, add the following block:

resource " oci_core_subnet " " example_subnet " {compartment_id = " < your_compartment_ocid > " display_name = " SNT-01 " vcn_id = oci_core_vcn.example_vcn.idcidr_block = " 10.0.0.0/24 " }

Note  the line where we set the VCN ID. Here we reference the OCID of the  previously declared VCN, using the name we gave it to Terraform:  example_vcn. This dependency makes Terraform provision the VCN first,  wait for OCI to return the OCID, then provision the subnet.

6. Run terraform plan to see that it will now create a VCN and subnet.

Add Variables

7.  Before moving on there are a few ways to improve the existing code.  Notice that the subnet and VCN both need the compartment OCID. We can  factor this out into a variable. Create a file named variables.tf

8. In variables.tf, declare a variable named compartment_id:

variable " compartment_id " {type = string}

9. In vcn.tf, replace all instances of the compartment OCID with var.compartment_id as follows:

terraform {required_providers {oci = {source = " oracle/oci " version = " > =4.67.3 " }}required_version = " > = 1.0.0 " } resource " oci_core_vcn " " example_vcn " {compartment_id = var.compartment_iddisplay_name = " VCN-01 " cidr_blocks = [ " 10.0.0.0/16 " ]} resource " oci_core_subnet " " example_subnet " {compartment_id = var.compartment_iddisplay_name = " SNT-01 " vcn_id = oci_core_vcn.example_vcn.idcidr_block = " 10.0.0.0/24 " }

Save your changes in both vcn.tf and variables.tf

10.  If you were to run terraform plan or apply now, Terraform would see a  variable and provide you a prompt to input the compartment OCID.  Instead, you’ll provide the variable value in a dedicated file. Create a  file named exactly terraform.tfvars

11. Terraform will  automatically load values provided in a file with this name. If you  were to use a different name, you would have to provide the file name to  the Terraform CLI. Add the value for the compartment ID in this file:

compartment_id = " < your_compartment_ocid > "

Be sure to save the file.

12. Run terraform plan and you should see the same output as before.

Provision the VCN

13. Run terraform apply and confirm that you want to make the changes by entering  yes  at the prompt.

14.  Navigate to VCNs in the console. Ensure that you have the right  compartment selected. You should see your VCN. Click its name to see the  details. You should see its subnet listed.

Terminate the VCN

15. Run terraform destroy. Enter  yes  to confirm. You should see the VCN terminate. Refresh your browser if needed.

Create and Destroy a VCN Using Resource Manager (You will most probably be tested on this in the actual certification)

We will reuse the Terraform code but replace the CLI with Resource Manager.

1.  Create a folder named terraform_vcn on your host machine. Download the  vcn.tf, terraform.tfvars, and variables.tf files from Code Editor and  move them to the terraform_vcn folder to your local machine. To download  from Code Editor, right-click the file name in the Explorer panel and  select  Download . You could download the whole folder at once, but then you would have to delete Terraform’s hidden files.

Create a Stack

2. Navigate to Resource Manager in the Console’s navigation menu under  Developer Services . Go to the  Stacks  page.

3. Click  Create stack .

a. The first page of the form will be for stack information.

  1) For the origin of the Terraform configuration, keep  My configuration  selected.

  2) Under  Stack configuration , upload your terraform_vcn folder.

  3) Under  Custom providers , keep  Use custom Terraform providers  deselected.

  4) Name the stack and give it a description.

  5) Ensure that your compartment is selected.

  6) Click  Next .

b. The second page will be for variables.

  1) Because you uploaded a terraform.tfvars file, Resource Manager will auto-populate the variable for compartment OCID.

  2) Click  Next .

c. The third page will be for review.

  1) Keep  Run apply  deselected.

  2) Click  Create . This will take you to the stack’s details page.

Run a Plan Job

4.  The stack itself is only a bookkeeping resource—no infrastructure was  provisioned yet. You should be on the stack’s page. Click  Plan . A form will pop up.

  a. Name the job RM-Plan-01.

  b. Click  Plan  again at the bottom to submit a job for Resource Manager to run terraform plan. This will take you to the job’s details page.

5. Wait for the job to complete, and then view the logs. They should match what you saw when you ran Terraform in Code Editor.

Run an Apply Job

6. Go back to the stack’s details page (use the breadcrumbs). Click  Apply . A form will pop up.

  a. Name the job RM-Apply-01.

  b. Under  Apply job plan resolution ,  select the plan job we just ran (instead of “Automatically approve”).  This makes it execute based on the previous plan, instead of running a  new one.

  c. Click  Apply  to submit a job for Resource Manager to run terraform apply. This will take you to the job’s details page.

7. Wait for the job to finish. View the logs and confirm that it was successful.

View the VCN

8. Navigate to VCNs in the Console through the navigation menu under  Networking  and  Virtual Cloud Networks .

9. You should see the VCN listed in the table. Click its name to go to its  Details  page.

10. You should see the subnet listed.

Run a Destroy Job

11. Go back to the stack’s details page in  Resource Manager .

12. Click  Destroy . Click  Destroy  again on the menu that pops up.

13. Wait for the job to finish. View the logs to see that it completed successfully.

14. Navigate back to VCNs in the Console. You should see that it has been terminated.

15. Go back to the stack in Resource Manager. Click the drop-down for  More actions . Select  Delete stack . Confirm by selecting  Delete .
