Dot matrix printersuse aninked ribbonthat physically contacts the paper through tiny pins. Over time, the ribbon wears out or dries up, resulting infaded or light print output. Replacing the ribbon restores print quality.

Option A:Cleaning helps with image clarity, not ink density.

Option C:Maintenance kits apply to laser printers, not dot matrix.

Option D:Calibration affects print position, not darkness.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 3.7: Given a scenario, troubleshoot common printer problems.

===========

When a workstation automatically assigns itself an IP address that is not part of the DHCP lease pool, the system has most likely configured an APIPA (Automatic Private IP Addressing) address. According to CompTIA Core 1 (220-1201) networking fundamentals, APIPA addresses fall within the range 169.254.0.0/16 and are assigned when a device cannot communicate with a DHCP server.

APIPA allows limited local network communication but does not provide access to the internet or network resources such as internal file shares that require routing or proper IP configuration. This explains why the workstation experiences connectivity issues.

A static IP address is manually configured and would not be automatically assigned. A DHCP address would come from the defined lease pool, which the technician has confirmed is not the case. A public IP address is assigned by an ISP and is not used directly on internal workstations.

CompTIA highlights APIPA as a key troubleshooting indicator of DHCP failure or network connectivity issues, making it the correct answer.

NFC (Near-Field Communication) is a subset of RFID technology designed for very short-range wireless communication, typically within a few centimeters. It is primarily used for contactless transactions, like mobile payments, and can also support peer-to-peer data exchanges. NFC operates at 13.56 MHz and enables devices to communicate when placed near each other.

If performance isnot a primary concernand the user requireslarge, cost-effective storage, a2TB 5400rpm SATA HDDis ideal. It offers high capacity at a lower price point than SSDs and faster HDDs.

Option A:NVMe drives offer exceptional speed but are significantly more expensive per GB and not necessary when read/write speed is not a concern.

Option B:RAID 1 improves redundancy but cuts usable capacity in half and uses expensive SSDs.

Option D:SAS drives are fast and reliable but are enterprise-grade and expensive overkill for desktop use.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 1.3: Given a scenario, install and configure storage devices.

PoE (Power over Ethernet) allows both data and electrical power to be delivered over the same Ethernet cable. A PoE injector adds power to Ethernet cables for devices that need it.

From CompTIA A+ 220-1101 Official Study Guide, Objective 2.2 – Networking hardware:

“Power over Ethernet (PoE) technology and PoE injectors enable both power and data transmission to compatible network devices like access points and IP cameras.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Network Hardware

CompTIA Exam Objectives 220-1101, Domain 2.2

============

When a newly built computer successfully passes POST, it indicates that the CPU, RAM, motherboard, video output, and other essential components are functioning at a hardware level. POST will typically fail or display error codes if there are problems with the CPU, RAM, GPU, or power delivery. Therefore, the fact that POST succeeds allows us to eliminate those components from suspicion.

The issue arises after POST, when the system attempts to load an operating system. For the OS to load, the BIOS/UEFI must detect a working storage device—such as an HDD, SSD, or NVMe drive—containing a bootable OS. If the computer cannot locate or read the drive, the system will halt at a boot error, such as “No boot device found,” “Insert boot media,” or similar messages. This is consistent with a failed or improperly connected HDD.

A failed HDD prevents access to boot files, even though the rest of the system hardware functions normally. Audio cards are irrelevant to booting. A failed CPU would cause a POST failure, not an OS loading issue. A faulty power supply would affect system stability during POST, not specifically OS boot failure unless the system is not powering at all.

Thus, the failed component is the HDD.

A VLAN (Virtual Local Area Network) is a network technology used to logically segment a physical network into multiple distinct broadcast domains, even if they share the same hardware.

From the CompTIA A+ 220-1101 Official Study Guide, Objective 2.2 – Compare and contrast common networking hardware:

“VLANs allow network administrators to segment a network logically, isolating broadcast traffic and improving security and management, regardless of the physical network layout.”

Other options explained:

MAC (Media Access Control) is a hardware address, not a segmentation method.

NIC (Network Interface Card) is network hardware, not for logical segmentation.

DSL (Digital Subscriber Line) is an internet connection type.

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Networking Concepts

CompTIA Exam Objectives 220-1101, Domain 2.2

A crimper is specifically used to attach RJ45 connectors to the ends of network cables. It pressesthe connector pins into the cable ' s wires, establishing a secure electrical connection. A punchdown tool is used for wiring patch panels or keystone jacks, not for attaching connectors.

Assigning a static IP to network printers ensures the printer ' s address does not change after outages or DHCP lease expirations, preventing connectivity issues.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.4 – Printer network configuration:

“Printers should use static IPs to ensure they remain reachable and do not change addresses after network events.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: Printer Networking

CompTIA Exam Objectives 220-1101, Domain 3.4

Intermittent VoIP call quality issues that occur during peak hours are a classic symptom of network congestion caused by voice and data traffic competing for the same network resources. According to CompTIA Core 1 (220-1201) networking and VoIP objectives, one of the most effective solutions is to configure VLANs to separate voice and data traffic.

By placing VoIP devices on a dedicated voice VLAN, the network can apply Quality of Service (QoS) policies that prioritize voice packets over standard data traffic. This reduces latency, jitter, and packet loss, which are the primary causes of poor call quality. VLAN separation ensures that even during heavy data usage, voice traffic remains clear and reliable.

Routing calls through a gigabit port does not address traffic prioritization and is unlikely to resolve congestion during peak usage. Installing shielded network cables only helps in environments with excessive electromagnetic interference, which would affect performance consistently—not intermittently. Increasing the VoIP bit rate would actually worsen congestion by consuming more bandwidth.

CompTIA emphasizes VLAN implementation and QoS as best practices for VoIP deployments, especially when call quality degrades under high network utilization.
