The access control rule in the exhibit has the following characteristics:

The rule name is DMZ_Rule and it is enabled.

The action set for this rule is Trust, meaning traffic matching this rule will not be subjected to further inspection.

The source zones are not specified, meaning any zone can match this rule.

The destination zone is DMZ_Inside, meaning only traffic destined to this zone can match this rule.

Therefore, the effect of this rule is that all traffic from any zone to the DMZ_Inside zone will be permitted with no further inspection. This is the correct answer, option A.

The other options are incorrect because they do not match the configuration of the rule or the behavior of the Trust action. Option B is incorrect because traffic will be allowed through to the DMZ_Inside zone, not blocked. Option C is incorrect because traffic will not be inspected before being allowed to the DMZ_Inside zone. Option D is incorrect because traffic does not need to be trusted to be allowed to the DMZ_Inside zone. References:

Firepower Management Center Configuration Guide, Version 6.6 - Access Control Rules

Firepower Management Center Device Configuration Guide, 7.1 - Access Control Policies

How to Deploy FMC/FTD part 2 – Access Control Policies

Cisco Stealthwatch is a network security and visibility platform that provides an agentless solution to monitor network traffic and detect threats, including those in encrypted traffic. Stealthwatch uses Encrypted Traffic Analytics (ETA), a technology that leverages network telemetry and machine learning to identify malicious patterns and behaviors in encrypted traffic without decryption. ETA can also assess the cryptographic strength and compliance of the encryption protocols used in the network. Stealthwatch integrates with other Cisco security products, such as Cisco Identity Services Engine (ISE) and Cisco Advanced Malware Protection (AMP), to provide contextual information and threat intelligence for faster and more effective response. Stealthwatch is the only Cisco platform that offers ETA as a solution to provide visibility across the network, including encrypted traffic analytics, to detect malware in encrypted traffic without the need for decryption. References :=

Some possible references are:

Cisco Secure Network Analytics (Stealthwatch) - Cisco, Cisco

Encrypted Traffic Analytics > Security | Cisco Press, Cisco Press

Solutions - Encrypted Traffic Analytics with the New Cisco Network and Secure Network Analytics At-a-Glance - Cisco, Cisco

Cisco Encrypted Traffic Analytics White Paper, Cisco

The Secure Event Connector is a component of the Security Analytics and Logging (SaaS) solution that enables the FMC to send logs to the cloud-based service. The Secure Event Connector uses syslog to forward events from the FMC and the managed devices to the cloud. This method reduces the load on the firewall resources, as the events are sent in batches and compressed before transmission. The Secure Event Connector also provides encryption, authentication, and reliability for the log data. The other methods are not supported by the Security Analytics and Logging (SaaS) solution12 References := 1: Cisco Security Analytics and Logging (On Premises)

DHCP option 82 is a feature that allows the network access device (NAD) to insert additional information into the DHCP request packet from the endpoint. This information can include the switch ID, port number, VLAN ID, and other attributes that can help Cisco ISE to identify and profile the endpoint. Cisco ISE can use DHCP option 82 to assign the endpoint to the appropriate identity group, policy, and authorization profile. DHCP option 82 is also useful to prevent rogue DHCP servers from assigning IP addresses to endpoints, as Cisco ISE can verify the legitimacy of the DHCP request based on the option 82 data. To use DHCP option 82, the NAD must be configured to enable this feature and send the option 82 data to Cisco ISE. Cisco ISE must also be configured to accept and parse the option 82 data from the NAD. For more details on how to configure DHCP option 82 on Cisco ISE and NAD, see the references below. References:

Configuring the DHCP Probe

Securing Your Network From DHCP Risks

Can we use ISE as DHCP/DNS server to prevent guest traffic using …

Explanation

Explanation

How To Troubleshoot ISE Failed Authentications & Authorizations

Check the ISE Live Logs

Login to the primary ISE Policy Administration Node (PAN).

Go to Operations > RADIUS > Live Logs

(Optional) If the event is not present in the RADIUS Live Logs, go to Operations > Reports > Reports >

Endpoints and Users > RADIUS Authentications

Check for Any Failed Authentication Attempts in the Log

Explanation

Cisco‘s Group Encrypted Transport VPN (GETVPN) introduces the concept of a trusted group to eliminate

point-to-point tunnels and their associated overlay routing. All group members (GMs) share a common security

association (SA), also known as a group SA. This enables GMs to decrypt traffic that was encrypted by any

other GM.

GETVPN provides instantaneous large-scale any-to-any IP connectivity using a group IPsec security paradigm.

The best way to prevent the session during the initial TCP communication is to configure policies to stop and reject communication from the known malicious domain. This will prevent the ESA from accepting any messages from that domain and send a negative SMTP response code back to the sender. This will also save the ESA’s resources and bandwidth, as it will not have to process or store the malicious emails. This can be done by creating a sender group in the Host Access Table (HAT) that matches the malicious domain and setting the mail flow policy to “Reject” or “Throttle”. Alternatively, a message filter can be created that checks the envelope sender against the malicious domain and applies the “stop_connection” or “reject_connection” action12.

The other options are not as effective as stopping and rejecting the communication at the TCP level. Configuring the Cisco ESA to drop the malicious emails (option A) will still allow the ESA to accept the messages and then silently discard them, which will consume the ESA’s resources and bandwidth, and also not notify the sender of the rejection. Configuring policies to quarantine malicious emails (option B) will also require the ESA to accept and store the messages, which will take up disk space and require manual or automated management of the quarantine. Configuring the Cisco ESA to reset the TCP connection (option D) will abruptly terminate the connection without sending a proper SMTP response code, which may cause the sender to retry the delivery and generate more traffic. Resetting the TCP connection is also considered a less polite and less compliant way of rejecting messages than sending a negative SMTP response code34. References: 1: How to Block a Sender Domain on the Email Security Appliance 2: Message Filters on the Cisco Email Security Appliance 3: How to Configure the Cisco Email Security Appliance to Reject or Drop Messages 4: Cisco Email Security Appliance User Guide - Configuring Mail Policies

Explanation

Application Visibility and control (AVC) supports NetFlow to export application usage and performance

statistics. This data can be used for analytics, billing, and security policies.

Explanation

The syntax of this command is shown below:

snmp-server group [group-name {v1 | v2c | v3 [auth | noauth | priv]}] [read read-view] [write write-view] [notify notify-view] [access access-list]

The command above restricts which IP source addresses are allowed to access SNMP functions on the router. You could restrict SNMP access by simply applying an interface ACL to block incoming SNMP packets that don’t come from trusted servers. However, this would not be as effective as using the global SNMP commands shown in this recipe. Because you can apply this method once for the whole router, it is much simpler than applying ACLs to block SNMP on all interfaces separately. Also, using interface ACLs would block not only SNMP packets intended for this router, but also may stop SNMP packets that just happened to be passing through on their way to some other destination device.

 Cisco Identity Services Engine (ISE) and AnyConnect Posture module are the best solution to ensure that all endpoints are compliant before users are allowed access on the corporate network. ISE is a policy-based platform that provides secure network access, identity management, and endpoint compliance. AnyConnect Posture module is a component of the AnyConnect Secure Mobility Client that performs posture assessment and remediation on the endpoints. Together, they can enforce policies based on the endpoint’s compliance status, such as the presence and update of the corporate antivirus application and the Windows 10 build version. The administrator can configure posture requirements, profiles, and policies on ISE, and deploy them to the endpoints through AnyConnect. The endpoints will then report their posture status to ISE, which will grant or deny network access accordingly, or redirect them to a remediation portal if needed. References :

GETVPN and IPsec are both VPN technologies that use ESP (Encapsulating Security Payload) to encrypt and authenticate data packets. However, they differ in the following aspects:

GETVPN uses a group IPSec security paradigm, which means that all group members share the same IPSec SA (Security Association) and can communicate with each other without having to establish point-to-point tunnels. IPsec, on the other hand, uses a pair-wise IPSec security paradigm, which requires each pair of devices to negotiate and maintain their own IPSec SAs and tunnels.

GETVPN uses GDOI (Group Domain of Interpretation) as a key management protocol, which allows a Key Server (KS) to distribute the encryption keys and policies to all group members. IPsec uses IKE (Internet Key Exchange) as a key management protocol, which involves two phases of negotiation between each pair of devices to establish the IPSec SAs.

GETVPN supports multicast traffic without the need for GRE (Generic Routing Encapsulation) tunneling, as it preserves the original IP header of the packet. IPsec does not support multicast traffic natively, and requires GRE tunneling to encapsulate the multicast packets with a new IP header.

GETVPN relies on the underlying WAN routing to deliver the encrypted packets to the destination, as it does not create any overlay routing. IPsec creates an overlay routing, which may introduce additional latency and complexity.

References :=

Some possible references are:

[Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0], Module 6: Secure Connectivity, Lesson 6.2: Implementing Site-to-Site VPNs, Topic 6.2.2: Group Encrypted Transport VPN

Group Encrypted Transport VPN (GETVPN)

GETVPN - Cisco Community

Cisco Get VPN vs DMVPN: Difference and Comparison

What is a difference between GETVPN and IPsec?

Explanation

Diffie Hellman (DH) uses a private-public key pair to establish a shared secret, typically a symmetric key. DH is not a symmetric algorithm – it is an asymmetric algorithm used to establish a shared secret for a symmetric key algorithm.

Explanation

Ping of Death (PoD) is a type of Denial of Service (DoS) attack in which an attacker attempts to crash,

destabilize, or freeze the targeted computer or service by sending malformed or oversized packets using a simple ping command.

A correctly-formed ping packet is typically 56 bytes in size, or 64 bytes when the ICMP header is considered,

and 84 including Internet Protocol version 4 header. However, any IPv4 packet (including pings) may be as large as 65,535 bytes. Some computer systems were never designed to properly handle a ping packet larger than the maximum packet size because it violates the Internet Protocol documented

Like other large but well-formed packets, a ping of death is fragmented into groups of 8 octets before

transmission. However, when the target computer reassembles the malformed packet, a buffer overflow can occur, causing a system crash and potentially allowing the injection of malicious code.

Before identifying the URL during HTTPS inspection in Cisco Secure Firewall Threat Defense software, the default action is to " pass. " This means that the traffic is allowed through without inspection until the URL can be identified, at which point appropriate security policies can be applied based on the URL categorization and reputation.
