Explanation

Explanation

To configure an NTP enabled router to require authentication when other devices connect to it, use the

following commands:

NTP_Server(config)#ntp authentication-key 2 md5 securitytut

NTP_Server(config)#ntp authenticate

NTP_Server(config)#ntp trusted-key 2

Then you must configure the same authentication-key on the client router:

NTP_Client(config)#ntp authentication-key 2 md5 securitytut

NTP_Client(config)#ntp authenticate

NTP_Client(config)#ntp trusted-key 2

NTP_Client(config)#ntp server 10.10.10.1 key 2

Note: To configure a Cisco device as a NTP client, use the command ntp server < IP address > . For example:

Router(config)#ntp server 10.10.10.1. This command will instruct the router to query 10.10.10.1 for the time.

Multifactor authentication (MFA) is a security measure that requires two or more proofs of identity to grant access to a resource, such as a username and password, a one-time code, a smart card, etc.1 MFA provides stronger protection than single-factor authentication (SFA), which only requires one proof of identity, such as a password. SFA can be compromised more easily by attackers who can guess, steal, or intercept passwords, or use phishing or social engineering techniques to trick users into revealing their credentials. MFA adds an extra layer of security that makes it harder for attackers to gain access, even if they have the password. MFA can also prevent unauthorized access from lost or stolen devices, as the attacker would need another factor to authenticate. MFA can also deter attackers from targeting an organization, as they would need to invest more time and resources to bypass the security measures. Therefore, organizations should migrate to a multifactor authentication strategy to enhance their security posture and protect their data and assets. References := 1: What is Multi-Factor Authentication (MFA)? - Auth0

Explanation

Cisco Cloudlock is a cloud-native cloud access security broker (CASB) that helps you move to the cloud safely. It protects your cloud users, data, and apps. Cisco Cloudlock provides visibility and compliance checks, protects data against misuse and exfiltration, and provides threat protections against malware like ransomware.

 The Cisco ESA uses the Sender Domain Reputation (SDR) service to assign a reputation verdict to each message based on the sender’s domain and other attributes. The SDR verdicts range from Awful to Good, and each verdict has a corresponding reputation score. The administrator can configure a message or content filter to take action on messages based on their SDR verdict or score. For example, the administrator can set a threshold score to drop messages that have a poor or awful reputation. However, if the SDR service cannot determine a verdict for a message, it assigns an undetermined verdict with a score of -1. This means that the message will not be dropped by the filter unless the administrator explicitly sets the threshold to -1 or lower. Therefore, the reason why the Cisco ESA is not dropping files that have an undetermined verdict is because the file has a reputation score that is above the threshold. References :=

Some possible references are:

Configure Sender Domain Reputation for ESA

Sender Domain Reputation Filtering

Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0 (source book)

Talos Intelligence is a comprehensive threat intelligence service that provides up-to-date information on URL filtering, reputations, and vulnerability information. Talos Intelligence can be integrated with Cisco FTD and Cisco WSA to enhance the security and visibility of the network. Cisco FTD and Cisco WSA can leverage the Talos Intelligence feeds to perform Security Intelligence filtering, which allows the devices to block or allow traffic based on the reputation of the source or destination IP addresses, URLs, or DNS requests. Talos Intelligence feeds are updated regularly and can be configured to download automatically or manually on the FTD and WSA devices12345. References := 1: Cisco Talos Intelligence Group - Comprehensive Threat Intelligence 2: Threat Intelligence on Cisco Stealthwatch - Cisco Community 3: Third-Party Integration of Security Feeds with FMC (Cisco Threat … - Cisco Community 4: Cisco Firepower Threat Defense Configuration Guide for Firepower Device … 5: Cisco Firepower Threat Defense Configuration Guide for Firepower Device …

 Grafana is an open source tool that displays graphs and counters for data streamed from network devices. Cisco uses Grafana to create graphical visualizations of network telemetry on Cisco IOS XE devices, which support model-driven telemetry. Model-driven telemetry is a new approach for network monitoring in which data is streamed from network devices continuously using a push model and provides near real-time access to operational statistics. Applications can subscribe to specific data items they need, by using standard-based YANG data models over NETCONF-YANG. Cisco IOS XE streaming telemetry allows to push data off of the device to an external collector at a much higher frequency, more efficiently, as well as data on-change streaming. Grafana uses the data from InfluxDB database to build dashboards and graphs. InfluxDB is a time-series database that stores the telemetry data received from the network devices. Telegraf is an agent that collects the telemetry data from the network devices and pushes it to InfluxDB. The TIG software stack refers to the three open-source software components that enable receiving, storing, and visualization the telemetry data: Telegraf, InfluxDB, and Grafana. References :=

Enterprise Streaming Telemetry and You: Getting Started with Model Driven Telemetry - Cisco Blogs

Explore Model-Driven Telemetry - Cisco Blogs

Telemetry Configuration Guide for Cisco 8000 Series Routers, IOS XR Release 7.8.x - Dial-Out Telemetry Session from Router to Destination

Free 350-701 Implementing and Operating Cisco Security Core Technologies Practice Test Questions

the file to Cisco Threat Grid for dynamic analysis. Cisco Threat Grid is a cloud-based service that provides malware analysis and threat intelligence. It can analyze suspicious files and URLs, and provide detailed reports on the behavior, indicators, and severity of the threat1. By sending the file to Cisco Threat Grid, the custom file policy can leverage the dynamic analysis results to detect the file as an indicator of compromise, and prevent other endpoints from executing the infected file. The other options are not correct because they do not address the root cause of the problem, which is the lack of detection by the custom file policy. Creating an IP block list, blocking the application, or uploading the hash for the file may help to mitigate the attack, but they do not ensure that the custom file policy is functioning as it should. References:

2: Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0 - Module 5: Endpoint Protection and Detection

3: Cisco AMP for Endpoints User Guide - Custom Detection Lists

4: Cisco AMP for Endpoints User Guide - File Analysis and Cisco Threat Grid

1: Cisco Threat Grid - Overview

Explanation

Only in On-site (on-premises) and IaaS we (tenant) manage O/S (Operating System).

Endpoint Protection Platform (EPP) and Endpoint Detection and Response (EDR) are both important components of an endpoint security strategy, but they have different goals and capabilities. EPP is designed to act as a preventive security measure, blocking known and unknown malware and malicious activity on endpoint devices using various techniques such as antivirus, data encryption, and data loss prevention. EPP solutions are mainly cloud-managed and assisted by cloud data, and use multiple detection engines such as signature-based, machine learning, and behavioral analysis. EPP solutions prevent breaches by leveraging threat intelligence and sandboxing capabilities to continuously protect endpoints from emerging threats12.

EDR, on the other hand, focuses on detecting and responding to advanced threats that have already evaded the front-line defenses and infiltrated the environment. EDR solutions provide continuous and comprehensive visibility into endpoint activity in real time, allowing security teams to quickly and effectively identify and remediate cyberattacks such as ransomware and fileless malware. EDR solutions offer advanced threat detection, investigation, and response capabilities, including incident data search and investigation, alert triage, suspicious activity validation, threat hunting, and malicious activity detection and containment. EDR solutions serve as a safety net to capture threats that go undetected by traditional antivirus software and uncover incidents that would otherwise remain invisible34.

Therefore, the primary difference between an EPP and an EDR is that EPP focuses on prevention, and EDR focuses on advanced threats that evade perimeter defenses. References: 1: Endpoint Protection Platform (EPP) Definition - Cisco 2: EPP vs. EDR: Why You Need Both - CrowdStrike 3: Endpoint Detection and Response (EDR) Definition - Cisco 4: EDR vs EPP: Why Should You Have to Choose? - Check Point Software

Asymmetric encryption, also known as public key cryptography, uses two different keys for encryption and decryption: a public key and a private key. The public key can be shared with anyone, while the private key must be kept secret. Data encrypted with the public key can only be decrypted with the private key, and vice versa. This ensures that only the intended recipient can access the encrypted data, and that the sender can prove their identity with a digital signature. Asymmetric encryption is widely used for securing Internet communications, such as TLS/SSL, which enables HTTPS. Some examples of asymmetric encryption algorithms are RSA, Diffie-Hellman, and Elliptic Curve Cryptography. The other options are not correct because they do not use a public key and private key. Symmetric encryption uses the same key for encryption and decryption, and is faster and more efficient than asymmetric encryption. However, symmetric encryption requires a secure way to exchange the key between the sender and the receiver, which can be facilitated by asymmetric encryption. Linear and nonlinear encryption are not types of encryption, but rather properties of encryption algorithms. A linear encryption algorithm is one that can be expressed as a linear function, such as XOR. A nonlinear encryption algorithm is one that involves more complex mathematical operations, such as modular arithmetic or S-boxes. Nonlinear encryption algorithms are generally more secure and resistant to cryptanalysis than linear encryption algorithms. References :=

Public-key cryptography - Wikipedia

How does public key cryptography work? - Cloudflare

Public and private encryption keys | PreVeil

AES encryption, what are public and private keys?

 A CI/CD pipeline is a process of automating the development, testing, and deployment of software applications. A CI/CD pipeline typically involves multiple tools and stages, such as source code management, build automation, testing, security scanning, and deployment. To secure a CI/CD pipeline, one of the best practices is to avoid hardcoding secrets in config files and CI/CD build tools, and instead use a secure access solution that can authenticate and authorize the access to the pipeline resources.

Duo Network Gateway is a cloud-based solution that provides secure access to internal web applications without requiring a VPN or modifying firewall rules. Duo Network Gateway integrates with Duo’s two-factor authentication (2FA) service to verify the identity of users and devices before granting access to the web applications. Duo Network Gateway also supports single sign-on (SSO) and identity federation with various identity providers, such as Active Directory, Azure AD, Google, and Okta.

By using Duo Network Gateway, you can leverage a CI/CD pipeline without exposing your internal web applications to the internet or compromising security. Duo Network Gateway can protect access to your source code repositories, build servers, testing tools, and deployment platforms. You can also enforce granular access policies based on user roles, device health, location, and time. Duo Network Gateway can help you achieve compliance with industry standards and regulations, such as PCI DSS, HIPAA, and GDPR.

The other options are not as suitable for securing access to a CI/CD pipeline as Duo Network Gateway. A remote access client is a software that allows users to connect to a remote network or server, such as a VPN client. However, a VPN client may not provide sufficient security for a CI/CD pipeline, as it may expose the entire network to potential attacks, or require complex firewall configurations and network segmentation. A VPN client may also introduce performance and reliability issues, as it depends on the quality and availability of the network connection.

SSL WebVPN is a feature of Cisco Adaptive Security Appliance (ASA) that allows users to access web-based resources securely over SSL/TLS. SSL WebVPN can provide secure access to web applications, email, file shares, and other network services. However, SSL WebVPN may not be able to support all the tools and stages of a CI/CD pipeline, as some of them may require non-web protocols, such as SSH, RDP, or VNC. SSL WebVPN may also require additional licenses and hardware resources to support a large number of concurrent users and connections.

Cisco FTD network gateway is a unified platform that combines the features of Cisco ASA and Cisco Firepower. Cisco FTD network gateway can provide firewall, intrusion prevention, malware protection, and VPN services. Cisco FTD network gateway can also integrate with Cisco Identity Services Engine (ISE) to provide identity-based access control and visibility. However, Cisco FTD network gateway may not be the best solution for securing access to a CI/CD pipeline, as it may require complex network design and deployment, and may not support all the CI/CD tools and protocols. Cisco FTD network gateway may also incur additional costs and maintenance efforts.

References := : Secure CI/CD Pipelines: Best Practices for Managing CI/CD Secrets : Duo Network Gateway | Duo Security : VPN vs. Duo Network Gateway | Duo Security : SSL VPN Deployment Guide for Cisco ASA - Cisco : Cisco Firepower Threat Defense Configuration Guide for Firepower Device Manager, Version 6.7 - VPN Overview [Cisco Firepower NGFW]

 Cisco Web Security Appliance (WSA) is the platform that automatically blocks risky sites, and tests unknown sites for hidden advanced threats before allowing users to click them, using Cisco Cognitive Threat Analytics. Cisco Cognitive Threat Analytics is a cloud-based solution that reduces the time to discovery of threats operating inside the network by analyzing web traffic and detecting anomalous behavior. Cisco WSA integrates with Cisco Cognitive Threat Analytics to provide enhanced web security and breach detection. Cisco WSA can also leverage other Cisco security solutions, such as Cisco Umbrella, Cisco Advanced Malware Protection (AMP), and Cisco Talos Intelligence Group, to provide comprehensive web security. References:

Cisco Web Security Appliance (WSA)

Cisco Cognitive Threat Analytics At-a-Glance

Introducing Cisco Cognitive Threat Analytics

Implementing and Operating Cisco Security Core Technologies (SCOR) - Module 3: Cloud and Content Security

 Phishing is a type of cyberattack that uses fraudulent emails or other communications to trick users into providing sensitive information or installing malware on their devices1. Phishing can lead to identity theft, data breaches, ransomware infections, and financial losses. To protect employees from phishing attacks, a company can use various solutions that can detect, block, and remediate phishing threats. Two of these solutions are:

Cisco Umbrella: Cisco Umbrella is a cloud-based security platform that provides the first line of defense against threats on the internet, including phishing2. Cisco Umbrella uses DNS-layer security, which can identify and block malicious domains, IPs, and URLs before they can reach the user’s device2. Cisco Umbrella also integrates with Cisco Email Security to provide additional protection against phishing emails that may bypass the email gateway3.

Cisco Email Security Appliance (ESA): Cisco ESA is an email gateway that protects inbound and outbound email traffic from spam, malware, phishing, and other threats4. Cisco ESA uses multiple layers of defense, such as reputation filtering, antivirus scanning, outbreak filters, and content filtering, to prevent malicious emails from reaching the user’s inbox4. Cisco ESA also leverages Cisco Advanced Phishing Protection, which uses machine learning and threat intelligence to identify and block sophisticated phishing attacks that use identity deception techniques5.

References := 1: What Is Phishing? Examples and Phishing Quiz - Cisco 2: Cisco Umbrella - Cloud Delivered Enterprise Security 3: Cisco Umbrella and Cisco Email Security Integration 4: Cisco Secure Email - Cisco 5: Cisco Advanced Phishing Protection - Cisco Video Portal

Dynamic ARP Inspection (DAI) is a security feature that validates ARP packets in a network. DAI allows a network administrator to intercept, log, and discard ARP packets with invalid MAC address to IP address bindings. This capability protects the network from certain “man-in-the-middle” attacks. DAI determines the validity of an ARP packet based on valid IP to MAC address bindings from the DHCP snooping binding database. DAI also supports static ARP ACLs for hosts with static IP addresses. DAI checks all ARP packets on untrusted interfaces, and only forwards the packets that have valid bindings. DAI can also rate-limit the ARP packets on untrusted interfaces to prevent DoS attacks. The other options are incorrect because:

B. In a typical network, DAI should be configured to make all ports as untrusted except for the ports connecting to trusted hosts or switches, which are trusted.

C. DAI does not associate a trust state with each switch, but with each interface on the switch.

D. DAI intercepts all ARP requests and responses on untrusted ports only, not on trusted ports. References :=

https://www.cisco.com/c/en/us/td/docs/switches/lan/catalyst4500/12-2/25ew/configuration/guide/conf/dynarp.html

https://study-ccna.com/dynamic-arp-inspection-dai/
